Vishay 100 V 40 A Switching Diode 2-Pin DO-203AB VS-40HF10

Vishay VS-40HF10 switching diode housed in a 2-pin DO-203AB package offers a robust and efficient solution for standard recovery rectifier needs in industrial and electronic applications. Rated for a maximum continuous forward current of 40 A and a peak reverse repetitive voltage of 100 V, this diode is suitable for power conversion circuits requiring reliable and high-efficiency switching performance.

The diode’s stud cathode configuration and screw mount design facilitate secure mechanical and electrical connections in various semiconductor circuits. With a low maximum forward voltage of 1.3 V, the device minimizes power losses and heat generation, contributing to improved circuit efficiency.

Operating effectively in extreme temperature ranges from -65°C up to 190°C, the VS-40HF10 ensures dependable performance even in harsh industrial environments such as manufacturing equipment, power supplies, and automotive electronics.

Designed to withstand peak non-repetitive forward surge currents up to 595 A, it accommodates transient load conditions typical in switching power supplies or motor controls. The compact physical dimensions of 20.08 mm length, 17.4 mm width, and 22.9 mm height allow integration into dense electronic layouts without compromising thermal dissipation.

This Vishay diode represents a versatile and industry-standard component for power rectification tasks, ideal for use in electronic manufacturing, industrial automation systems, and power electronics assemblies requiring durable semiconductor switching solutions.

Features a maximum continuous forward current of 40 amperes. Supports peak reverse repetitive voltage of 100 volts for reliable operation. Constructed in industry-standard DO-203AB package with stud cathode diode configuration.

Maximum forward voltage drop is 1.3 volts ensuring efficient switching performance. Operates within a temperature range of -65°C to 190°C for extended environmental durability. Capable of handling peak non-repetitive forward surge current up to 595 amperes.

Compact dimensions with length 20.08 mm, width 17.4 mm, height 22.9 mm, and diameter 17.4 mm. Designed for applications requiring reliable standard recovery rectifiers in power electronics. 2-pin screw mount package allowing secure installation in electronic assemblies.
