Nexperia 20 V 1 A Schottky Diode Surface Mount Package SOD-323 BAT760,115

Free Delivery in India | Lowest Global Shipping Charges

Nexperia 20 V 1 A Schottky Diode Surface Mount Package SOD-323 BAT760,115

Name: Nexperia 20 V 1 A Schottky Diode Surface Mount Package SOD-323 BAT760,115
Brand: Nexperia
SKU: 394686
Price: 20.22 USD
Availability: InStock



Category Schottky Barrier Diode Brand Nexperia Condition New

Specifications

Country of Origin	China
Brand	Nexperia
Height	1.05mm
Length	1.8mm
Model	BAT760,115
Width	1.35mm
Mount Type	Surface
Series	BAT76
Maximum Operating Temperature	125°C
Package Type	SOD-323
Minimum Operating Temperature	-65°C
Pin Count	2
Maximum Continuous Forward Current If	1A
Peak Reverse Repetitive Voltage Vrrm	20V
Diode Configuration	Single
Rectifier Type	Schottky
Peak Reverse Current Ir	50μA
Peak Non-Repetitive Forward Surge Current Ifsm	5A
Maximum Forward Voltage Vf	550mV
onsemi 30 V 1 A Schottky Barrier Diode Schottky 2-Pin SOD-323 NSR1020MW2T1GBrand	onsemi

Key Features

Compact SOD-323 package suitable for space-constrained applications.
High efficiency with low forward voltage drop of 550 mV.
Peak non-repetitive forward surge current capability up to 5 A.
Wide operating temperature range from -65°C to 125°C for robust performance.
Low leakage current with peak reverse current of only 50 μA.
Single diode configuration ideal for rectification and switching.
Ultra-small, low-profile design for streamlined PCB layouts.
Optimized for low capacitance and negligible switching losses.

Product Description

Nexperia BAT760,115 Schottky Diode is a high-performance, surface-mount semiconductor device designed for power rectification and switching applications. Featuring a 2-pin SOD-323 package, it supports a maximum continuous forward current of 1 A and a peak reverse repetitive voltage of 20 V, making it suitable for use in compact electronic circuits requiring efficient low-voltage drop diodes.

The diode offers excellent thermal and electrical characteristics with a maximum forward voltage drop of 550 mV and the ability to handle peak non-repetitive forward surge currents of up to 5 A. It operates reliably within a temperature range of -65°C to 125°C, making it versatile for various environmental conditions.

Its design emphasizes ultra-small size and low profile for space-saving PCB assembly while maintaining low capacitance and negligible power switching losses. The diode exhibits minimal leakage current (peak reverse current of 50 μA), supporting energy-efficient operation in sensitive electronics.

Compact SOD-323 package suitable for space-constrained applications. High efficiency with low forward voltage drop of 550 mV. Peak non-repetitive forward surge current capability up to 5 A. Wide operating temperature range from -65°C to 125°C for robust performance.

Low leakage current with peak reverse current of only 50 μA. Single diode configuration ideal for rectification and switching. Ultra-small, low-profile design for streamlined PCB layouts. Optimized for low capacitance and negligible switching losses.

Manufactured in China under Nexperia brand quality standards.

This Schottky diode is widely used in industrial, electronic components, power supply circuits, automotive electronics, and other fields requiring reliable diode performance with minimal power loss.

Explore more high-quality semiconductor components and Schottky diodes in our Electronics & Electricals offerings at EnvMart.

Explore more products in our Schottky Barrier Diode category.
