Molex Mini-Fit Sr Series Straight Through Hole PCB Header 2 Contacts 10 mm Pitch 1 Row Shrouded 42819-2213

Name: Molex Mini-Fit Sr Series Straight Through Hole PCB Header 2 Contacts 10 mm Pitch 1 Row Shrouded 42819-2213
Brand: Molex
SKU: 368700
Price: 7.69 USD
Availability: InStock



Category PCB Headers Brand Molex Condition New

Specifications

Country of Origin	India
Voltage	600V
Brand	Molex
Orientation	Straight
Current	50A
Mount Type	Through Hole
Housing Material	Thermoplastic
Contact Material	Brass
Series	Mini-Fit Sr
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Number of Rows	1
Pitch	10mm
Contact Plating	Gold
Number of Contacts	2
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board
428xx-x2x2	Tin plated contact area
428xx-x2x3	Gold plated contact area
428xx-x21x	1.57 mm nominal PCB thickness
428xx-x22x	2.36 mm nominal PCB thickness
428xx-x23x	3.18 mm nominal PCB thickness
428xx-x24x	6.35 mm nominal PCB thickness

Key Features

Operates at a maximum voltage of 600V and current of 50A.
Features a 10 mm pitch with one row and a shrouded housing for secure connection.
Constructed with thermoplastic housing and gold-plated brass contacts for corrosion resistance.
Designed for through-hole mounting with solder termination for robust PCB attachment.
Works reliably within temperature ranges from -40°C to 105°C.
Compatible with Mini-Fit Sr cable receptacle housings for versatile wire-to-board applications.
Includes metal PCB retention clips for improved mechanical stability on the board.
Suitable for industrial, electronic manufacturing, and power connector applications.

Product Description

Molex 42819-2213 Mini-Fit Sr Series Straight Through Hole PCB Header is engineered for high-performance wire-to-board connectivity, featuring a shrouded design with 2 gold-plated male contacts spaced at 10 mm pitch in a single row. It supports a maximum operating voltage of 600V and current rating of 50A, making it ideal for demanding electronic and power applications.

Housed in durable thermoplastic, the header is designed for through-hole mounting and uses solder termination to ensure a secure and reliable connection to printed circuit boards. The connector operates effectively in environments with temperatures ranging from -40°C to 105°C. The inclusion of metal retention clips adds mechanical stability, preventing loosening during high-vibration or industrial use.

This PCB header is compatible with Mini-Fit Sr cable receptacle housings, allowing flexible assembly options for wire-to-board applications in industrial, manufacturing, power distribution, and electronic component systems. Its brass contacts plated with gold ensure excellent electrical conductivity and corrosion resistance for long service life.

Maximum Voltage: 600V with current rating of 50A. Pitch: 10 mm with a single row of contacts. Mounting type: Through Hole with solder termination. Operating temperature range: -40°C to 105°C. Housing Material: Thermoplastic, Shrouded design.

Contact Material: Brass with gold plating. Includes PCB retention clips for mechanical stability. Ideal for industrial, electronic manufacturing, power supply, and wiring applications. Explore more PCB header connectors and power connectors in the Electronics & Electricals category at EnvMart.
