Samtec SQT Series Right Angle Through Hole PCB Socket 6-Contact 1 Row 2 mm Pitch Solder SQT-106-01-L-S-RA
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 450V |
| Brand | Samtec |
| Orientation | Right Angle |
| Current | 5.5A |
| Temperature range | -55 → 125 °C |
| Model | SQT-106-01-L-S-RA |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Bronze |
| Current Rating | 5.5 A at 20 °C |
| Series | SQT |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Board-to-Board |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2mm |
| Contact Plating | Gold |
| Number of Contacts | 6 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
| Insulator Material | Black LCP |
| SQT-1xx-01-L-S | single row vertical |
| SQT-1xx-01-L-x-RA | horizontal |
| SQT-1xx-01-L-D | double row vertical |
Key Features
- Constructed with a Liquid Crystal Polymer housing for durability and stability.
- Designed for through-hole mounting with a right angle orientation.
- Supports a current rating of 5.5 A at 20 °C and voltage of 450 V.
- Contacts are made of bronze with gold plating to ensure excellent conductivity.
- Operating temperature range from -55 °C to 125 °C suitable for rigorous industrial environments.
- Provides rugged reliability with 0.5 mm square contacts and matte tin plated PCB tails.
- Compatible with single row vertical, horizontal, and double row vertical SQT Series options.
- Ideal for use in electronics manufacturing, power connectors, industrial control, and PCB assembly applications.
Product Description
Samtec SQT-106-01-L-S-RA is a Right Angle Through Hole PCB Socket with 6 contacts arranged in a single row and 2 mm pitch solder termination. It incorporates a durable Liquid Crystal Polymer (LCP) housing and features bronze contacts with a 0.25 μm gold plating on contact surfaces for superior electrical performance.
The socket supports a maximum current of 5.5 A at 20 °C and a voltage rating of 450 V, suitable for demanding electronic and power connector applications. Its operating temperature range from -55 °C to 125 °C ensures reliable functionality in harsh industrial, laboratory, and manufacturing environments.
The SQT series uses Tiger Buy 0.5 mm square contacts and matte tin plating on 0.5 mm square PCB tails, providing rugged and long-lasting board-to-board connections. This model is specifically designed for through-hole mounting with a right angle orientation to fit compact PCB layouts.
This socket series is available in various row and orientation options, including single row vertical, horizontal, and double row vertical formats, offering flexibility for diverse design needs.
Applications include electronic components assembly, industrial electronics, power connector systems, and high-reliability PCB socket installations. Durable Liquid Crystal Polymer housing and gold-plated bronze contacts for high conductivity.
Single row, 6 contact configuration with 2 mm pitch for board-to-board connection. Rated for 5.5 A current and 450 V voltage with wide operating temperature range. Right angle through-hole mount designed for compact PCB integration.
Robust design suitable for industrial, laboratory, and manufacturing environments. Offered in various SQT Series configurations to match application requirements. Supports high performance and reliable interconnections on PCB assemblies.
Discover more PCB Sockets and power connectors in the Electronics & Electricals category at EnvMart. Explore our wide range to find the ideal component for your industrial or commercial electronic systems.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a maximum current rating of 5.5 A at 20 °C.
It is rated for a maximum voltage of 450 V.
The operating temperature range is from -55 °C to 125 °C.
The contacts are made of bronze and feature a 0.25 μm gold plating for enhanced conductivity.
This socket has 6 contacts arranged in a single row.
It is designed for through-hole mounting with a right angle orientation.
The pitch size is 2 mm.
It is ideal for use in electronics manufacturing, power connectors, industrial control, and PCB assembly applications.
The housing is constructed from Liquid Crystal Polymer (LCP) for durability and stability.
The SQT series includes configurations such as single row vertical, horizontal, and double row vertical options.
The insulator material is black Liquid Crystal Polymer (LCP).
The country of origin for this product is India.
