HARTING Har-Flex Series Straight Surface PCB Socket 50-Contact 2 Row 1.27 mm Pitch Solder 15210502601000
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 125V |
| Brand | HARTING |
| Orientation | Straight |
| Current | 750mA |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Copper |
| Series | Har-Flex |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Wire-to-Board |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 1.27mm |
| Contact Plating | Gold |
| Number of Contacts | 50 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- Features 50 female contacts arranged in 2 rows with a 1.27 mm pitch.
- Current rating of 750 mA and voltage rating of 125 V ensure reliable connectivity.
- Constructed with copper contacts plated in gold for durability and conductivity.
- Housing made from liquid crystal polymer offers ruggedness and thermal stability.
- Supports surface mount technology with straight orientation for versatile PCB design.
- Operates in temperature ranges from -55°C to 125°C, suitable for various environments.
- Part of the Har-Flex series, known for space-saving and flexible board-to-board connector solutions.
- Suitable for mezzanine, extender-card, mother-to-daughtercard, and cable-to-board applications.
Product Description
HARTING 15210502601000 Har-Flex Series Straight Surface PCB Socket is a 50-contact, 2-row surface mount connector with a 1.27 mm pitch designed for board-to-board connectivity in industrial and electronic applications.
This PCB socket supports a current rating of 750 mA and voltage rating of 125 V, making it suitable for a variety of power and signal transmission tasks. The contacts are female gender, made of copper and plated with gold to ensure low resistance and high durability under repeated mating cycles.
The housing material is liquid crystal polymer which provides mechanical robustness and excellent thermal performance, supporting operating temperatures from -55°C to 125°C. The straight orientation facilitates easy and space-efficient PCB layout, especially in complex mezzanine or extender card applications.
The Har-Flex series is noted for its rugged, flexible design and space-saving profile, which accommodates a scalable range of contact counts from 6 to 100, allowing custom configurations for diverse electronic device interconnects. This connector series is ideal for industrial, manufacturing, and power connector applications requiring reliable solder termination and high precision.
Features 50 female contacts arranged in 2 rows with a 1.27 mm pitch. Constructed with copper contacts plated in gold for optimal conductivity. Housing made of liquid crystal polymer ensures durability and thermal stability.
Supports surface mount technology with straight orientation. Operates reliably within -55°C to 125°C temperature range. Current and voltage ratings are 750 mA and 125 V respectively. Part of space-saving, scalable Har-Flex series.
Ideal for mezzanine and extender card board-to-board applications. Manufactured in China under stringent quality standards. Designed for industrial, electronic, and power connector uses. Explore more HARTING connectors and related PCB Sockets in the Electronics & Electricals category at EnvMart, your trusted platform for industrial components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The voltage rating of this PCB socket is 125 V.
This model has a current rating of 750 mA.
The contacts are arranged with a pitch of 1.27 mm.
The contacts are made of copper and plated with gold, while the housing is constructed from liquid crystal polymer.
It operates reliably within a temperature range of -55°C to 125°C.
This model features 50 female contacts arranged in 2 rows.
The termination type for this connector is solder.
The connector has a straight orientation, facilitating easy PCB layout.
It is suitable for mezzanine, extender-card, mother-to-daughtercard, and cable-to-board applications.
This model is part of a board-to-board connector system.
This product is manufactured in China under stringent quality standards.
Gold plating on the contacts ensures low resistance and high durability under repeated mating cycles.
