HARTING Har-Flex Series Straight Surface PCB Socket, 50-Contact, 2 Row, 1.27 mm Pitch, 125V, 750mA 15210502601000

Free Delivery in India | Lowest Global Shipping Charges

HARTING Har-Flex Series Straight Surface PCB Socket, 50-Contact, 2 Row, 1.27 mm Pitch, 125V, 750mA 15210502601000

Name: HARTING Har-Flex Series Straight Surface PCB Socket, 50-Contact, 2 Row, 1.27 mm Pitch, 125V, 750mA 15210502601000
Brand: HARTING
SKU: 363155
Price: 7.41 USD
Availability: InStock



Category PCB Socket Brand HARTING Condition New

Specifications

Country of Origin	China
Voltage	125V
Brand	HARTING
Orientation	Straight
Current	750mA
Mount Type	Surface
Housing Material	Liquid Crystal Polymer
Contact Material	Copper
Series	Har-Flex
Termination Type	Solder
Maximum Operating Temperature	125°C
Sub Type	Wire-to-Board
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	1.27mm
Contact Plating	Gold
Number of Contacts	50
Contact Gender	Female
Connector System	Board-to-Board

Key Features

Features a straight surface mount design for PCB applications.
Constructed with a liquid crystal polymer housing for durability.
Operates at a voltage of 125V and current of 750mA.
Contacts are copper with gold plating to ensure reliable connections.
Designed for a temperature range from -55°C to 125°C.
Compatible with board-to-board and wire-to-board systems.
Offers scalable contact counts from 6 to 100 for flexible system designs.
Suitable for mezzanine, extender-card, and daughterboard applications.

Product Description

HARTING 15210502601000 Har-Flex Series Straight Surface PCB Socket is a high-quality, general-purpose connector designed for robust internal and external device board connections in SMT technology. With 50 contacts arranged in two rows at a 1.27 mm pitch, this socket facilitates space-saving and flexible system designs.

The socket housing is made of liquid crystal polymer, providing excellent durability and stability under demanding industrial conditions. The contact pins are crafted from copper and plated with gold to ensure optimal electrical conductivity and resistance to corrosion. Operating voltage is rated at 125V with a current carrying capacity of 750mA, suitable for a wide range of electronics applications.

Its straight surface mount orientation makes it ideal for board-to-board connections in mezzanine stacks, extender cards, or daughtercard assemblies. The product operates reliably within a temperature range from -55°C to 125°C and conforms to the UL 94-V0 flammability standard, ensuring safety in electronic assemblies.

The Har-Flex series stands out for its ruggedness, flexibility, and scalability, allowing designers to customize contact counts for different applications. It supports both wire-to-board and board-to-board configurations, offering high freedom in system layout and interconnection.

50-contact, 2-row configuration with 1.27 mm pitch. Liquid crystal polymer housing for robust performance. Copper contacts with gold plating for reliable conductivity. Current rating of 750mA and operating voltage of 125V.

Wide operating temperature range from -55°C to 125°C. Compliant with UL 94-V0 standards for safety. Ideal for mezzanine, extender card, and daughterboard connections. Space-saving and scalable connector design. Supports SMT technology for surface mounting.

This HARTING Har-Flex Series PCB Socket is engineered for industrial, manufacturing, electronics, and telecommunications applications requiring reliable and flexible PCB connections. It is manufactured in China and comes with new product condition assurance. Explore more HARTING connectors and related power connectors at EnvMart for your next project needs.
