Vishay 45 V 6 A Schottky Barrier Rectifier Surface Mount TO-252 Package V6PWL45HM3/I
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Model | V6PWL45HM3/I |
| Mount Type | Surface |
| Series | eSMP |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-252 |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 6A |
| Peak Reverse Repetitive Voltage Vrrm | 45V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Non-Repetitive Forward Surge Current Ifsm | 100A |
| Maximum Forward Voltage Vf | 0.38V |
Key Features
- Low forward voltage drop enhances energy efficiency.
- Utilizes trench MOS barrier Schottky technology for superior performance.
- Compact DPAK (TO-252) package enables automated PCB assembly.
- Operates within temperature range from -40°C to 175°C.
- Rated for peak forward surge current of 100 A for transient tolerance.
- Certified RoHS compliant and meets AEC-Q101 automotive qualification.
- Ideal for DC/DC conversion, freewheeling diode, and polarity protection applications.
- Very low profile with typical height of 1.3 mm supports compact designs.
Product Description
Vishay V6PWL45HM3/I is a high performance Schottky barrier rectifier designed for efficient low voltage, high frequency applications. This diode supports a maximum continuous forward current of 6 amperes and peak reverse voltage of 45 volts, packaged in a surface mount TO-252 (DPAK) case.
The device uses advanced trench MOS barrier Schottky technology to minimize forward voltage drop and power losses, boosting overall circuit efficiency and thermal performance. Its low profile of approximately 1.3 mm height makes it suitable for compact electronic assemblies.
Rated for operation in harsh environments with a broad temperature range from -40°C to 175°C, the rectifier also withstands a peak non-repetitive surge current of 100 amperes, making it robust against transient conditions. It is RoHS compliant and meets the rigorous automotive standard AEC-Q101, signifying high reliability.
Ideal use cases include DC/DC converters, freewheeling diodes in power electronics, and polarity protection circuits. The surface mount package facilitates automated placement and soldering during manufacturing, improving production efficiency.
Low forward voltage drop enhances energy efficiency. Advanced trench MOS barrier Schottky construction reduces power dissipation. Compact TO-252 (DPAK) surface mount package. Wide operating temperature range from -40°C to 175°C.
Peak surge current rating of 100 A for transient tolerance. RoHS compliant and meets automotive standard AEC-Q101. Suitable for DC/DC converters, polarity protection, and freewheeling diode roles. Very low profile design with 1.3 mm typical height.
This rectifier component is essential for industrial, automotive, telecommunications, and consumer electronics requiring efficient, reliable power management. Explore the comprehensive range of Vishay Schottky diode solutions on EnvMart for your advanced semiconductor requirements.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current rating for this model is 6 amperes.
This Schottky barrier rectifier has a peak reverse voltage rating of 45 volts.
It operates within a temperature range from -40°C to 175°C.
The diode is packaged in a surface mount TO-252 (DPAK) case.
The peak non-repetitive forward surge current rating is 100 amperes.
Yes, this model is RoHS compliant.
It meets the AEC-Q101 automotive standard, indicating high reliability for automotive applications.
The maximum forward voltage drop is 0.38 volts.
It is ideal for DC/DC converters, freewheeling diodes, and polarity protection applications.
The typical height of the TO-252 package is approximately 1.3 mm.
This model uses a single diode configuration.
The country of origin for this product is India.
