Taiwan Semiconductor Bridge Rectifier Through Hole TS-6PL Package Quad Configuration 1000 V 15 A 208 A T15JA07G-K

Name: Taiwan Semiconductor Bridge Rectifier Through Hole TS-6PL Package Quad Configuration 1000 V 15 A 208 A T15JA07G-K
Brand: Taiwan Semiconductor
SKU: 298857
Price: 20.22 USD
Availability: InStock



Category Bridge Rectifier Brand Taiwan Semiconductor Condition New

Specifications

Country of Origin	India
Brand	Taiwan Semiconductor
Height	30mm
Length	29.3mm
Model	T15JA07G-K
Mount Type	Through Hole
Configuration	Quad
Maximum Operating Temperature	150°C
Package Type	TS-6PL
Minimum Operating Temperature	-55°C
Number of Phases	1
Standards/Approvals	RoHS, UL, IEC 61249-2-21
Pin Count	4
Peak Reverse Repetitive Voltage Vrrm	1000V
Peak Reverse Current Ir	0μA
Peak Non-Repetitive Forward Surge Current Ifsm	208A
Forward Current If	15A
Peak Forward Voltage Vf	1.1V

Key Features

This bridge rectifier operates at a maximum temperature of 150°C.
It has a peak non-repetitive forward surge current of 208 A.
The device is RoHS compliant and UL recognized for safety standards.
Glass passivated chip junction ensures durability and reliability.
Ideal for use in switching mode power supplies, adapters, and lighting applications.
Its package length is 29.3 mm and height is 30 mm for easy PCB integration.
Halogen-free according to IEC 61249-2-21 standards.
The device operates reliably between -55°C to 150°C.

Product Description

Taiwan Semiconductor T15JA07G-K Bridge Rectifier is a high-performance 4-Pin Quad semiconductor device housed in a TS-6PL through-hole package. It is designed to withstand peak reverse repetitive voltages up to 1000 V and maintain continuous forward current of 15 A, making it suitable for demanding power rectification tasks.

The bridge rectifier features a robust glass passivated chip junction that enhances long-term stability and reliability. With a peak non-repetitive forward surge current rating of 208 A, it is capable of handling transient power spikes without damage. This device operates safely within a temperature range from -55°C to 150°C, making it ideal for various industrial and commercial electronic applications.

Its compact package dimensions of 29.3 mm length and 30 mm height allow for convenient installation on printed circuit boards. The product complies with RoHS environmental directives, is UL recognized, and is halogen-free as per IEC 61249-2-21, ensuring safety and environmental friendliness.

Common applications include switching mode power supplies (SMPS), adapters, and lighting systems where efficient power conversion and reliability are essential. The through-hole mount type facilitates strong mechanical connection in rugged environments.

This bridge rectifier offers high surge current capability to handle temporary overloads. Designed for excellent performance in electronic and power management circuits. Suitable for use in industrial, laboratory, HVAC, and manufacturing environments.

Halogen-free and RoHS compliant providing eco-friendly operation. UL Certified ensuring compliance with international safety standards. Browse EnvMart's comprehensive selection of semiconductor devices and Bridge Rectifiers to find the ideal component for your electronic design projects.
