Taiwan Semiconductor Bridge Rectifier, 200 V 8 A Forward Current, 200 A Surge, 4-Pin Through Hole GBU803
Specifications
| Country of Origin | China |
|---|---|
| Brand | Taiwan Semiconductor |
| Height | 18.8mm |
| Length | 22.3mm |
| Model | GBU803 |
| Width | 3.56mm |
| Mount Type | Through Hole |
| Series | GBU8 |
| Configuration | Single |
| Maximum Operating Temperature | 150°C |
| Package Type | GBU |
| Minimum Operating Temperature | -55°C |
| Number of Phases | 1 |
| Pin Count | 4 |
| Automotive Standard | AEC-Q101 |
| Peak Reverse Repetitive Voltage Vrrm | 200V |
| Peak Reverse Current Ir | 500μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 200A |
| Forward Current If | 8A |
| Peak Forward Voltage Vf | 1.1V |
| Taiwan Semiconductor Bridge Rectifier, 600 V 200 A, 4-Pin SingleBrand | Taiwan Semiconductor |
Key Features
- Handles a peak reverse repetitive voltage of 200 V for reliable AC to DC conversion.
- Supports a forward current of 8 A with a peak non-repetitive surge current of 200 A.
- Operates efficiently within a temperature range of -55°C to 150°C.
- Features a compact 22.3 mm length and 18.8 mm height suitable for PCB through-hole applications.
- Complies with AEC-Q101 automotive standard ensuring durability under automotive conditions.
Product Description
Taiwan Semiconductor GBU803 Bridge Rectifier is a 4-pin single-phase semiconductor device engineered for converting alternating current (AC) input into direct current (DC) output. It supports a peak reverse repetitive voltage (VRRM) of 200 V and a forward current (IF) of 8 A, making it suitable for a variety of electronic applications.
This bridge rectifier is designed for Printed Circuit Board (PCB) through-hole mounting, providing mechanical stability and reliable soldering performance. Its compact dimensions include 22.3 mm length, 18.8 mm height, and 3.56 mm width, catering to space-constrained electronic assemblies.
The device withstands a maximum operating temperature of 150°C and a minimum of -55°C, ensuring stable performance under harsh thermal conditions. The GBU803 features a peak non-repetitive forward surge current (IFSM) of 200 A and a low peak forward voltage (VF) of 1.1 V, contributing to efficient power conversion with minimal losses.
Additionally, it adheres to the AEC-Q101 automotive standard, making it suitable for automotive electronics requiring high reliability and performance. The typical peak reverse current (IR) is very low at 500 μA, which improves the efficiency of rectification.
Bridge rectifiers like the GBU803 are widely used in industrial, electronic, automotive, and power supply applications for rectification and power conversion tasks. Their robust design allows use in environments demanding electrical and thermal endurance.
Handles a peak reverse repetitive voltage of 200 V for reliable AC to DC conversion. Supports a forward current of 8 A with a peak non-repetitive surge current of 200 A. Operates within -55°C to 150°C for versatile thermal tolerance.
Compact 4-pin package designed for through-hole PCB mounting. Complies with AEC-Q101 automotive standard for enhanced durability. Explore EnvMart's comprehensive range of semiconductor Bridge Rectifiers and power components for your industrial and electronic design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The GBU803 has a peak reverse repetitive voltage (VRRM) of 200 V, making it suitable for reliable AC to DC conversion.
This model supports a forward current (IF) of 8 A, allowing it to handle various electronic applications effectively.
It can withstand a peak non-repetitive forward surge current (IFSM) of 200 A, which is beneficial for handling transient conditions.
The dimensions of this unit are 22.3 mm in length, 18.8 mm in height, and 3.56 mm in width, making it compact for PCB applications.
The GBU803 operates efficiently within a temperature range of -55°C to 150°C, ensuring stable performance in varying conditions.
This bridge rectifier is designed for through-hole mounting on printed circuit boards (PCBs), providing mechanical stability.
Yes, it complies with the AEC-Q101 automotive standard, ensuring it meets the reliability requirements for automotive applications.
The peak forward voltage (VF) for this model is 1.1 V, contributing to its efficient power conversion capabilities.
The typical peak reverse current (IR) for the GBU803 is very low at 500 μA, which enhances its rectification efficiency.
This model features a 4-pin configuration, suitable for various electronic circuit designs.
It is configured as a single-phase bridge rectifier, which is standard for AC to DC conversion applications.
The GBU803 is part of the GBU8 series of bridge rectifiers, designed for efficient power conversion.
