DiodesZetex Bridge Rectifier 200 V 100 A Surface Mount, DFS Package 4-Pin DF02S-T

DiodesZetex DF02S-T Bridge Rectifier is a high-reliability, surface-mount semiconductor device tailored for efficient AC to DC conversion in electronic power circuits. Featuring a durable DFS package with 4 pins, this single-phase bridge rectifier offers a peak reverse repetitive voltage of 200 V and a forward current rating of 1 A, making it suitable for a wide range of industrial and consumer electronics applications.

The device operates reliably within a temperature range of -65°C to 150°C, supporting both demanding industrial environments and commercial electronics. Its glass passivated die construction ensures longevity and superior electrical performance, while the low forward voltage drop of 1.1 V enhances energy efficiency in rectification tasks.

With compact dimensions measuring 8.51 mm in length, 6.5 mm in width, and 2.6 mm in height, the rectifier is optimized for PCB surface mounting, facilitating compact and dense electronic designs. Additionally, the device withstands peak non-repetitive forward surge currents up to 100 A, enabling it to handle transient power spikes without damage.

Applications for the DiodesZetex DF02S-T bridge rectifier include power supplies, motor control, battery charging, HVAC systems, and industrial equipment where converting alternating current to direct current is crucial. Its reliable performance ensures stable power delivery and protection of downstream components.

The DFS package design suitable for automated PCB assembly. High surge current capability ensures resilience to power transients. Wide operating temperature range supports varied environmental conditions. Low forward voltage drop reduces power loss and heat generation.

Compact size enables integration in space-constrained applications. Glass passivated die construction provides durability and stability. Single-phase bridge rectifier configuration supports a variety of circuit designs. Peak reverse repetitive voltage of 200 V for robust voltage endurance.

Pin count of 4 facilitates standard bridge rectifier arrangements. Explore more DiodesZetex semiconductor products and Bridge Rectifiers in the Electronics & Electricals category on EnvMart for all your design and manufacturing needs.
