Molex Nano-Fit Series Straight Through Hole PCB Header 4 Contacts 2.5 mm Pitch 2 Row Shrouded 105310-1104

Free Delivery in India | Lowest Global Shipping Charges

Molex Nano-Fit Series Straight Through Hole PCB Header 4 Contacts 2.5 mm Pitch 2 Row Shrouded 105310-1104

Name: Molex Nano-Fit Series Straight Through Hole PCB Header 4 Contacts 2.5 mm Pitch 2 Row Shrouded 105310-1104
Brand: Molex
SKU: 218850
Price: 1.88 USD
Availability: InStock



Category PCB Header Brand Molex Condition New

Specifications

Country of Origin	China
Voltage	250V
Brand	Molex
Orientation	Straight
Current	6.5A
Mount Type	Through Hole
Contact Material	Brass
Series	Nano-Fit
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Number of Rows	2
Pitch	2.5mm
Contact Plating	Tin
Number of Contacts	4
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board
Tail Pin Length	3.2mm

Key Features

This PCB header supports a current rating of 6.5A, suitable for robust electrical connections.
It features brass contact material with tin plating for reliable conductivity and corrosion resistance.
The header is designed for through hole mount with a straight orientation and male contact gender.
Operating temperature range is from -40°C minimum to a maximum of 105°C, enabling wide application in electronics.
Includes solder termination type with a 3.2 mm tail pin length for secure PCB soldering.
The Nano-Fit series is noted for its ultra-low mate force terminal and positive-lock housing with anti-snag design.
Offers support for multi-layer boards by eliminating the need for through holes and provides multiple mechanical keying options.

Product Description

Molex 105310-1104 Nano-Fit Series Straight Through Hole PCB Header is a versatile connector designed for use in electronic circuitry requiring durable and efficient wire-to-board connections. The product has 4 contacts arranged in 2 rows with a 2.5 mm pitch and a shrouded housing that provides protection against accidental disconnections and mechanical damage.

Constructed with brass contacts plated with tin, this PCB Header offers excellent electrical conductivity and reliable mechanical strength. It supports a continuous current of 6.5A and operates within a temperature range of -40°C to 105°C, making it suitable for a wide range of industrial, manufacturing, and electronic applications.

The header uses through hole mounting with straight orientation, allowing for solid PCB attachment, and its male contact gender paired with solder termination ensures a secure and long-lasting connection. The 3.2 mm tail pin length accommodates various PCB board thicknesses and solder assembly needs.

The Nano-Fit series is recognized for its ultra-low mating force which reduces wear and tear during repeated connection cycles. The positive-lock housing includes an anti-snag design facilitating easy insertion and removal without damage. Its design eliminates the necessity for through holes in multi-layer PCB boards, enabling compact and efficient circuit layouts. Multiple mechanical keying and color-coded options are available to prevent mismating and enhance PCB design flexibility.

This product is ideal for electronics manufacturing, industrial control equipment, instrumentation, and communication devices. The headers come in embossed tape packaging, making them compatible with pick-and-place assembly machines.

Each terminal provides 4-point contact to ensure low resistance and secure electrical pathways. Retention tang and contact rib features improve mechanical stability during operation. Perfect for water treatment controls, HVAC systems, automotive, and commercial electronics where reliable PCB connections are critical.

Country of Origin: China. Explore more PCB connector solutions to find the ideal fit for your electronic equipment requirements here at EnvMart.
