DiodesZetex PNP Bipolar Transistor -2 A, -100 V, 3-Pin SOT-23 ZXTP25100BFHTA

DiodesZetex ZXTP25100BFHTA is a high-quality PNP bipolar transistor designed for general-purpose semiconductor applications. It supports a maximum DC collector current of -2 A and collector-emitter voltage of -100 V, making it suitable for moderate power switching and amplification tasks in electronic circuits.

The device comes in a compact 3-pin SOT-23 surface mount package with dimensions of 3 mm length, 2.5 mm width, and 1.1 mm height. This package type allows for efficient PCB space usage and compatibility with automated assembly processes.

Key electrical characteristics include a maximum power dissipation of 1.81 W, maximum collector-base voltage of -140 V, and maximum emitter-base voltage of -7 V. The ZXTP25100BFHTA transistor also features a minimum DC current gain (hFE) of 15 and a high-frequency transition frequency of 200 MHz, supporting versatile use in high-frequency switching and amplification.

This transistor complies with the automotive AEC-Q101 standard, ensuring robustness and reliability in automotive and industrial electronic applications. It operates reliably in a temperature range from -55°C to 150°C, suitable for harsh environmental conditions.

Suitable for industrial, automotive, power management, and consumer electronics applications, this transistor enhances circuit performance where a reliable PNP bipolar transistor is required.

Designed for general-purpose applications requiring surface mount technology. Maximum power dissipation of 1.81 W ensures reliable performance under load. Supports automotive standard AEC-Q101, suitable for automotive electronics.

Wide operating temperature range from -55°C to 150°C accommodates harsh environments. High transition frequency of 200 MHz allows use in high-frequency circuits. Compact dimensions of 3 mm length, 2.5 mm width, and 1.1 mm height facilitate PCB space efficiency.

Single transistor configuration with PNP polarity ideal for complementary transistor circuits. Minimum DC current gain (hFE) of 15 provides assured gain under operating conditions. Designed to surface mount type with 3 pins, compatible with various PCB assembly techniques.
