Taiwan Semiconductor Bridge Rectifier, 600 V, 144 A, 4-Pin Quad Configuration TS-6PL Through Hole Mount T15JA05G-K
Specifications
| Country of Origin | India |
|---|---|
| Brand | Taiwan Semiconductor |
| Height | 30mm |
| Length | 29.3mm |
| Model | T15JA05G-K |
| Mount Type | Through Hole |
| Configuration | Quad |
| Maximum Operating Temperature | 150°C |
| Package Type | TS-6PL |
| Minimum Operating Temperature | -55°C |
| Number of Phases | 1 |
| Standards/Approvals | UL, RoHS, IEC 61249-2-21 |
| Pin Count | 4 |
| Peak Reverse Repetitive Voltage Vrrm | 600V |
| Peak Reverse Current Ir | 0μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 144A |
| Forward Current If | 15A |
| Peak Forward Voltage Vf | 1.1V |
Key Features
- The semiconductor provides a peak reverse repetitive voltage of 600 V.
- Standard through-hole mount type with a compact size of 29.3mm length and 30mm height.
- Maximum forward current is 15 A, suitable for power supply applications.
- Operates reliably within a temperature range of -55°C to 150°C.
- Quad configuration with 4 pins ensures efficient circuit integration.
- Features glass passivated chip junction for durability.
- High surge current capability up to 144 A for transient protection.
- Complies with UL, RoHS, and IEC 61249-2-21 standards.
Product Description
Taiwan Semiconductor T15JA05G-K Bridge Rectifier is a high-quality discrete semiconductor designed for industrial and electronic power applications. With a peak reverse repetitive voltage of 600 V and peak non-repetitive forward surge current of 144 A, it provides dependable rectification performance. The device features a glass passivated chip junction enhancing longevity and is provided in a TS-6PL package with a quad configuration and through-hole mounting style.
This bridge rectifier operates efficiently with a maximum forward current rating of 15 A and withstands temperatures ranging from -55°C to 150°C, making it suitable for demanding conditions. The compact physical dimensions of approximately 29.3 mm in length and 30 mm in height allow for easy integration into circuit boards.
The rectifier complies with important industry standards including UL recognition, RoHS compliance for hazardous substance restrictions, and halogen-free manufacturing according to IEC 61249-2-21. It is ideal for use in switching mode power supplies (SMPS), electrical adapters, and lighting equipment, providing high surge current tolerance and robust operation.
The product includes a 4-pin quad configuration ensuring easy and stable installation on printed circuit boards. Its halogen-free and RoHS-compliant construction aligns with environmental safety regulations. Glass passivated chip junction technology improves reliability and extends service life.
Operates within a broad temperature range suitable for diverse industrial environments. High surge current capacity protects equipment from transient surges and spikes.
This bridge rectifier combines performance, compliance, and environmental considerations, making it suitable for industrial, manufacturing, commercial electronics, HVAC systems, and laboratory power supply applications. It exemplifies reliability demanded by professionals designing and maintaining power rectification circuits.
Explore more semiconductor and bridge rectifier products at EnvMart for dependable electrical components and integrated solutions.
Explore more products in our Discrete Semiconductors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The bridge rectifier has a peak reverse repetitive voltage of 600 V.
This model has a maximum forward current rating of 15 A.
It can handle a peak non-repetitive forward surge current of up to 144 A.
The dimensions are approximately 29.3 mm in length and 30 mm in height.
It operates reliably within a temperature range of -55°C to 150°C.
It features a through-hole mounting type, allowing for stable installation on circuit boards.
This model has a quad configuration with 4 pins.
It complies with UL, RoHS, and IEC 61249-2-21 standards.
The package type is TS-6PL.
The peak forward voltage is 1.1 V.
It is suitable for use in switching mode power supplies (SMPS), electrical adapters, and lighting equipment.
The country of origin for this product is India.
