Molex 10-Way IDC Connector Female for Surface Mount, 1 Row, 1.2A Current, 250V AC, Picoflex Series 90816-0010

Free Delivery in India | Lowest Global Shipping Charges

Molex 10-Way IDC Connector Female for Surface Mount, 1 Row, 1.2A Current, 250V AC, Picoflex Series 90816-0010

Name: Molex 10-Way IDC Connector Female for Surface Mount, 1 Row, 1.2A Current, 250V AC, Picoflex Series 90816-0010
Brand: Molex
SKU: 215655
Price: 1.33 USD
Availability: InStock



Category IDC Connector Brand Molex Condition New

Specifications

Country of Origin	Ireland
Voltage	250V ac
Brand	Molex
Orientation	Straight
Current	1.2A
Mount Type	Surface
Housing Material	Polyphthalamide
Contact Material	Brass
Series	Picoflex
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Number of Rows	1
Pitch	1.27mm
Contact Plating	Tin
Number of Contacts	10
Contact Gender	Female
Connector Gender	Female
Shrouded/Unshrouded	Unshrouded

Key Features

Supports a current rating of 1.2 amperes for reliable performance.
Operates at a voltage of 250 volts AC ensuring safety in electrical circuits.
Features a 1.27 mm pitch spacing for compact design.
Constructed with brass contacts plated with tin for durability and corrosion resistance.
Housing made from polyphthalamide material providing high thermal and chemical resistance.
Designed for surface mounting with straight orientation for easy PCB integration.
Rated for operation across a temperature range from -40°C to 105°C for various environments.
Utilizes solder termination type and is unshrouded for easy connection.

Product Description

Molex 90816-0010 10-Way IDC Connector Female is a high-quality surface mount IDC connector designed for electronic applications requiring a compact and reliable wire-to-board interface. It features one row of 10 female contacts with a pitch of 1.27 mm, operating safely at 1.2 A current and 250 V AC voltage.

The connector employs brass contacts plated with tin to ensure excellent electrical conductivity while resisting corrosion. The housing is made of durable polyphthalamide material which withstands high temperatures and harsh environments. This connector supports solder termination, enabling straightforward and secure PCB mounting.

Rated for minimum and maximum operating temperatures of -40°C and 105°C respectively, it is suitable for automotive, consumer electronics, and other industrial applications where vibration and shock resistance is essential. The positive latch mechanism and polarized side posts provide increased retention and prevent improper mating.

This connector is part of Molex's Picoflex series, which offers a 50% space saving compared to traditional pitch connectors, making it ideal for high-density assemblies. Its low mated height of 6.4 mm and integral strain relief design contribute to its reliability and compact footprint.

Supports 1.2A current and 250V AC voltage rating. Features brass contacts with tin plating for durability. Polyphthalamide housing offers high thermal resistance. Unshrouded female IDC connector with single row of 10 contacts.

Surface mount type with straight orientation. Operating temperature range from -40°C to 105°C. Positive latch and polarization to ensure secure connection. Part of the space-saving Picoflex series. Suitable for automotive, consumer electronics, and industrial applications.

This Molex IDC Connector is an excellent choice for engineers and designers requiring reliable, compact interconnect solutions in electronic assemblies. Explore more components and connectors to suit diverse industrial and commercial requirements at EnvMart.
