| Country of Origin | India |
|---|---|
| Brand | DiodesZetex |
| Height | 2.3mm |
| Length | 4.6mm |
| Model | S1M-13-F |
| Width | 2.92mm |
| Mount Type | Surface |
| Series | S1M |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214AC |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 1A |
| Peak Reverse Repetitive Voltage Vrrm | 1kV |
| Diode Configuration | Single |
| Rectifier Type | General Purpose |
| Peak Reverse Current Ir | 100μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 30A |
| Maximum Forward Voltage Vf | 1.1V |
| Peak Reverse Recovery Time trr | 3μs |
DiodesZetex S1M-13-F is a high-performance general purpose Schottky diode encapsulated in a compact 2-pin DO-214AC surface mount package. It supports a maximum continuous forward current of 1A and can withstand peak reverse repetitive voltage of up to 1 kV, making it suitable for demanding rectification and switching tasks.
This diode delivers a maximum forward voltage of only 1.1V, which minimizes power loss and enhances efficiency in power conversion applications. The peak reverse current is low at 100μA, ensuring effective blocking capability. The diode's rapid switching speed with a 3μs peak reverse recovery time makes it suitable for high-frequency applications.
Designed to operate reliably in harsh environmental conditions, it features a broad operating temperature range from -65°C to 150°C. The diode’s peak non-repetitive forward surge current rating of 30A allows it to handle transient current surges without damage.
With physical dimensions of length 4.6mm, width 2.92mm, and height 2.3mm, the S1M-13-F fits compact electronic assemblies efficiently. This makes it ideal for industrial, laboratory, and commercial applications including power supply rectification, voltage clamping, and reverse polarity protection.
DiodesZetex maintains strict manufacturing standards, although no specific certifications or automotive standards are indicated for this component. It is widely applicable in discrete semiconductor roles where durability and performance reliability are required.
This diode supports surface mount technology for streamlined PCB assembly. Typical uses include power rectifiers, freewheeling diodes, and general semiconductor circuit applications. The product is brand new and sourced directly from DiodesZetex with model and MPN as S1M-13-F.
Package type DO-214AC ensures mechanical stability and easy soldering. Ideal for electronic component inventories targeting smart device manufacturing and repair.
