Renesas Electronics Analogue Switch CMOS Logic Family 16-Pin SOIC 4 Elements DG442DYZ
Specifications
| Country of Origin | India |
|---|---|
| Brand | Renesas Electronics |
| Model | DG442DYZ |
| Output type | CMOS/TTL |
| Series | DG442 |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Pin Count | 16 |
| Number of Elements per Chip | 4 |
| Maximum Supply Voltage | 34V |
| Logic Family | CMOS |
| Minimum Supply Voltage | -5V |
| Maximum On State Resistance | 200Ω |
Key Features
- Consists of four independent single pole single throw (SPST) analog switches for versatile signal control.
- Outputs compatible with CMOS and TTL logic for broad integration.
- Operates with single or split supply voltages ranging from -5V to 34V.
- Maximum on-state resistance of 200Ω ensures reliable signal transmission.
- Wide operating temperature range from -40°C to 85°C suits industrial environments.
- Monolithic CMOS construction reduces charge injection and improves signal integrity.
- Encased in a 16-pin SOIC package ideal for compact PCB layouts.
- Non-automotive series DG442 designed for various electronic component applications.
Product Description
Renesas Electronics DG442DYZ analogue switch is a monolithic CMOS device comprising four independent single pole single throw (SPST) switches housed in a 16-pin SOIC package. It operates within a wide voltage range of -5V (minimum supply) to 34V (maximum supply), offering efficient and compatible switching functionality for electronic signal control applications.
The device's CMOS logic family design ensures compatibility with both CMOS and TTL output types, providing versatility for integration into diverse circuits. Each switch element exhibits a maximum on-state resistance of 200Ω, facilitating stable signal transmission with minimal loss.
Operating temperature ranges from -40°C to 85°C enable reliable performance in demanding industrial and commercial environments. The DG442DYZ's low charge injection design reduces signal distortion and enhances switching precision, making it suitable for sensitive analogue signal routing tasks.
The compact 16-pin SOIC package supports space-saving PCB design while maintaining accessibility for surface mount assembly. This series is not automotive grade and is positioned for general electronic component usage in advanced multiplexer and demultiplexer IC applications.
Four independent SPST analog switches provide flexible switching control. CMOS/TTL compatible outputs enable broad circuit integration. Single or split supply operation supports wide voltage ranges. Low charge injection minimizes signal interference.
Sustains industrial operating temperature conditions. Compact 16-pin SOIC package for efficient PCB layout. Non-automotive DG442 series for general electronic component use.
This analogue switch suits a spectrum of applications including industrial automation, control systems, audio and video signal switching, and semiconductor testing equipment. Suitable for laboratory, manufacturing, and embedded system designs requiring precise analogue signal routing.
Explore more Electronic Components and semiconductor solutions in the Electronics & Electricals category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum supply voltage for this model is 34V.
It operates within a temperature range of -40°C to 85°C, making it suitable for industrial environments.
This model consists of four independent single pole single throw (SPST) switches.
The outputs are compatible with both CMOS and TTL logic, allowing for broad integration into various circuits.
The maximum on-state resistance is 200Ω, ensuring reliable signal transmission.
It is encased in a 16-pin SOIC package, which is ideal for compact PCB layouts.
The minimum supply voltage for the DG442DYZ is -5V.
This model belongs to the CMOS logic family.
It is suitable for applications including industrial automation, control systems, audio and video signal switching, and semiconductor testing equipment.
Yes, it supports both single and split supply operation within its specified voltage range.
The low charge injection design reduces signal distortion and enhances switching precision, making it suitable for sensitive analogue signal routing tasks.
The country of origin for this model is India.
