Renesas Electronics 0.75MHz XO Oscillator 25 ppm LVDS 4-Pin VCXO XLH736022.579200I

Renesas Electronics XLH736022.579200I is a 0.75MHz XO oscillator with 25 ppm frequency stability, featuring low voltage differential signaling (LVDS) output and housed in a compact 4-pin VCXO surface mount package. It provides ultra-precision timing with low phase jitter, making it highly suitable for critical timing applications in electronics and communications.

This device operates with a supply voltage of 2.5V or 3.3V and functions reliably within an operating temperature range of -20°C to 70°C for standard use cases, with extended temperature support (-40°C to +105°C) available for the XO variant. Measuring only 7 mm in length, 5 mm in width, and 1.3 mm in height, it is optimized for space-constrained PCBs.

The oscillator’s phase jitter performance ranges from 750 to 890 femtoseconds across the 12 kHz to 20 MHz bandwidth, achieved through Renesas proprietary ASIC technology focused on noise reduction. This product is RoHS compliant, supporting environmentally friendly manufacturing.

With LVDS output and surface mount design, it is ideal for integration into high-precision industrial, laboratory, communication systems, semiconductor manufacturing equipment, and other commercial electronics requiring stable frequency references.

The XL series oscillators cover a frequency range from 0.75 MHz up to 1350 MHz, and this specific XLH736022.579200I model delivers a focused performance at 0.75 MHz with excellent stability and low jitter characteristics.

Frequency stability of 25 ppm ensures minimal frequency drift during operation. Surface mount 4-pin VCXO package form factor aids in compact electronic assemblies. Supply voltage flexibility allows compatibility with various electronic designs.

Compliance with RoHS provides assurance of meeting environmental standards. Explore more in the Electronics Components > Crystal Oscillator category for compatible and complementary products on EnvMart.
