Vishay 40 V 1 A Schottky Diode Surface Mount DO-213AB BYM13-40-E3/96
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 2.41mm |
| Brand | Vishay |
| Height | 2.67mm |
| Length | 5.2mm |
| Model | BYM13-40-E3/96 |
| Width | 2.67mm |
| Mount Type | Surface |
| Maximum Operating Temperature | 125°C |
| Package Type | DO-213AB |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 1A |
| Peak Reverse Repetitive Voltage Vrrm | 40V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 500μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 30A |
| Maximum Forward Voltage Vf | 0.7V |
Key Features
- This diode is designed for high performance with very low forward voltage drop.
- It features a fast switching action suitable for low power loss applications.
- The peak reverse repetitive voltage is 40 volts, with a peak reverse current of 500 microamperes.
- Rated maximum forward voltage is 0.7 volts and maximum continuous forward current is 1 ampere.
- The package dimensions include 5.2 mm length, 2.67 mm width and height, and 2.41 mm diameter.
- Peak non-repetitive forward surge current rating is 30 amperes for surge tolerance.
- Operating temperature ranges from -55°C to 125°C making it suitable for varying conditions.
- The diode complies with RoHS 2002/95/EC, UL 94V-0, and WEEE 2002/96/EC standards and meets automotive standard AEC-Q101.
Product Description
Vishay BYM13-40-E3/96 is a high performance Schottky diode designed for surface mounting in a compact DO-213AB package. It supports a maximum continuous forward current of 1 ampere and a peak reverse repetitive voltage of 40 volts.
These diodes exhibit very low forward voltage drop with a fast switching action, making them ideal for applications that require high efficiency and low power loss. The diode's peak forward surge current rating of 30 amperes ensures tolerance against transient surges.
The diode's operating temperature range from -55°C to 125°C extends its utility under harsh industrial and automotive environments. The device complies with RoHS directive and automotive quality standards (AEC-Q101), ensuring reliability and regulatory compliance.
Dimensions of 5.2 mm length, 2.67 mm width and height, and a diameter of 2.41 mm facilitate compact circuit board layouts. High performance Schottky rectifier diode with fast switching capability. Low forward voltage drop for increased efficiency.
1 ampere continuous forward current rating. 40 volts peak reverse voltage rating. Compact DO-213AB surface mount package. Wide operating temperature range from -55°C to 125°C. Compliance with RoHS, UL 94V-0, WEEE, and AEC-Q101 automotive standard.
This Schottky diode is suitable for diverse applications including power management, automotive electronics, and industrial control systems. Its fast switching and low loss characteristics make it ideal for rectification and protection circuits in electronics manufacturing and design.
Explore more electronic semiconductor components at EnvMart for your industrial, commercial, or laboratory needs.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current rating is 1 ampere.
The peak reverse repetitive voltage is 40 volts.
The package dimensions are 5.2 mm in length, 2.67 mm in width and height, with a diameter of 2.41 mm.
The operating temperature range is from -55°C to 125°C.
The maximum forward voltage drop is 0.7 volts.
The peak non-repetitive forward surge current rating is 30 amperes.
It complies with RoHS 2002/95/EC, UL 94V-0, WEEE 2002/96/EC, and automotive standard AEC-Q101.
This diode has a pin count of 2.
It supports surface mounting.
The peak reverse current is 500 microamperes.
It is a Schottky rectifier diode.
The country of origin is India.
