| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 2.29mm |
| Length | 4.5mm |
| Model | S1A-E3/61T |
| Width | 2.79mm |
| Mount Type | Surface |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214AC |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | RoHS |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 1A |
| Peak Reverse Repetitive Voltage Vrrm | 50V |
| Diode Configuration | Single |
| Rectifier Type | General Purpose |
| Peak Reverse Current Ir | 50μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 40A |
| Maximum Forward Voltage Vf | 1.1V |
| Peak Reverse Recovery Time trr | 1.8μs |
Vishay S1A-E3/61T is a general purpose Schottky diode designed for surface mounting in industries such as electronics manufacturing, automotive systems, telecommunications, and power supplies. It operates with a maximum continuous forward current of 1 ampere and withstands peak reverse repetitive voltage up to 50 volts, making it suitable for switching and rectification purposes.
This diode features a low forward voltage (Vf) of 1.1 volts which contributes to energy efficiency by minimizing conduction losses. Its peak reverse recovery time of 1.8 microseconds allows for faster switching speeds beneficial in high-frequency circuits. It tolerates a wide temperature range from -55°C to 150°C, ensuring stable performance in harsh environments.
The device comes in a compact DO-214AC package with dimensions of 4.5 mm length, 2.79 mm width, and 2.29 mm height, enabling space-saving surface mount designs. It adheres to RoHS compliance and meets automotive industry standard AEC-Q101, confirming its reliability for automotive electronic applications.
Ideal for use in power management circuits, signal demodulation, protection circuits, and other discrete semiconductor needs, this diode delivers a balance of efficiency, robustness, and compactness to suit industrial, laboratory, and commercial electronics applications.
Maximum continuous forward current of 1 ampere. Peak reverse repetitive voltage of 50 volts. Low forward voltage drop of 1.1 volts. Wide operating temperature range from -55°C to 150°C. Compact DO-214AC surface mount package.
Fast peak reverse recovery time of 1.8 microseconds. RoHS and AEC-Q101 automotive standard compliant. Suitable for industrial and automotive electronic applications. Explore the Vishay range and related semiconductor devices available at EnvMart for your electronic component needs.
Explore more products in our Schottky Diodes & Rectifiers category.
