Molex Mini-Latch Series Straight Through Hole Pin Header 12 Contacts 2.5 mm Pitch 1 Row Unshrouded 22-04-1121
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Molex |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | Mini-Latch |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2.5mm |
| Contact Plating | Tin |
| Number of Contacts | 12 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire-to-Board |
Key Features
- Designed for wire-to-board applications with friction ramp locking mechanism for secure mating.
- Features a straight orientation and through-hole mount type for easy PCB installation.
- Constructed with brass contacts plated in tin and nylon housing for durability.
- Operates within a voltage of 250V and current rating of 3A.
- Suitable for operating temperatures from -40°C to 105°C.
- Offers a single row with 12 pin contacts spaced at 2.5 mm pitch.
- Termination type is solder, ensuring strong electrical connections.
- Unshrouded male contacts provide easy access for mating connectors.
Product Description
Molex 22-04-1121 Mini-Latch Series Straight Through Hole Pin Header is a high-quality PCB connector designed for wire-to-board applications. Featuring 12 male brass contacts with tin plating housed in durable nylon, it has a 2.5 mm pitch and single row configuration providing efficient circuit connections. This unshrouded pin header is designed with a friction locking ramp mechanism ensuring secure and reliable mating with compatible connectors in various electronic devices.
The product supports a maximum voltage of 250V and a current rating of 3A, withstanding operating temperatures from -40°C to 105°C, making it suitable for a wide range of environments. Its through-hole mount type facilitates robust circuit board assembly, commonly used in vehicles, printers, fax machines, PC monitors, and data communication centers.
This Mini-Latch pin header offers design flexibility with straight orientation and compatibility with 2.50 mm Mini-Latch crimp housings and KK series connectors. The solder termination type provides reliable electrical and mechanical connections essential in industrial and commercial electronics manufacturing.
Designed for wire-to-board applications with friction ramp locking mechanism for secure mating. Features a straight orientation and through-hole mount type for easy PCB installation. Constructed with brass contacts plated in tin and nylon housing for durability.
Operates within a voltage of 250V and current rating of 3A. Suitable for operating temperatures from -40°C to 105°C. Offers a single row with 12 pin contacts spaced at 2.5 mm pitch. Termination type is solder, ensuring strong electrical connections.
Unshrouded male contacts provide easy access for mating connectors.
This connector is ideally suited for industrial manufacturing, electronic components assembly, communications electronics, and automotive applications where reliable wiring connections are critical. It supports various standard Mini-Latch series housings for seamless integration in complex wiring systems.
Explore the wide range of Molex components and PCB connector solutions available at EnvMart for all your electronic design and production requirements.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This pin header operates at a maximum voltage of 250V and has a current rating of 3A.
It features a pitch of 2.5 mm and includes 12 male contacts in a single row configuration.
This connector utilizes a through-hole mount type for easy installation on PCBs.
The contacts are made of brass with tin plating, while the housing is constructed from nylon.
It is suitable for operating temperatures ranging from -40°C to 105°C.
This model features a solder termination type, ensuring strong electrical connections.
Yes, it is compatible with 2.50 mm Mini-Latch crimp housings and KK series connectors.
The pin header has a straight orientation, which aids in easy connection.
The contacts in this model are male, providing unshrouded access for mating connectors.
It is designed for wire-to-board applications and is commonly used in vehicles, printers, and data communication centers.
The country of origin for this pin header is India.
This connector is part of the Mini-Latch series, known for its reliable locking mechanism.
