Molex Mini-Latch Series Straight Through Hole Pin Header, 13 Contact, 2.5 mm Pitch, 1 Row Unshrouded 22-04-1131

Free Delivery in India | Lowest Global Shipping Charges

Molex Mini-Latch Series Straight Through Hole Pin Header, 13 Contact, 2.5 mm Pitch, 1 Row Unshrouded 22-04-1131

Name: Molex Mini-Latch Series Straight Through Hole Pin Header, 13 Contact, 2.5 mm Pitch, 1 Row Unshrouded 22-04-1131
Brand: Molex
SKU: 212005
Price: 1.17 USD
Availability: InStock



Category PCB Headers Brand Molex Condition New

Specifications

Country of Origin	India
Voltage	250V
Brand	Molex
Orientation	Straight
Current	3A
Mount Type	Through Hole
Housing Material	Nylon
Contact Material	Brass
Series	Mini-Latch
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Number of Rows	1
Pitch	2.5mm
Contact Plating	Tin
Number of Contacts	13
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded
Connector System	Wire-to-Board

Key Features

Features 13 brass male contacts with tin plating for corrosion resistance.
Constructed with nylon housing material ensuring durability and electrical insulation.
Designed for through-hole mounting and solder termination type.
Operates within a voltage rating of 250V and current rating of 3A.
Suitable for operating temperatures from -40°C to 105°C.
Unshrouded design provides easy access for connections.
Includes friction locking ramp providing secure mating connections.
Ideal for use in vehicles, fax machines, printers, PC monitors, and data communication centers.

Product Description

Molex 22-04-1131 Mini-Latch Series Straight Through Hole Pin Header is a high-quality PCB connector with 13 male contacts arranged in a single row with a 2.5 mm pitch. The unshrouded design facilitates easy and reliable wire-to-board interfacing. Constructed from durable nylon housing and brass contacts plated with tin, this pin header ensures consistent electrical performance while maintaining robust mechanical strength.

This through-hole mounted connector supports a maximum current of 3A and voltage rating of 250V. It is designed to operate reliably in harsh environments, with a temperature range covering from -40°C to 105°C. The friction locking ramp mechanism provides a secure mating connection, preventing accidental disconnections in various industrial and commercial applications.

The Molex Mini-Latch 22-04-1131 is compatible with Mini-Latch 51191 series and KK series 5051 2.5 mm crimp housings, offering design flexibility with vertical mounting options. Applications include automotive harnesses, office equipment like fax machines and printers, PC monitors, as well as data communication centers requiring reliable wire-to-board connections.

Features 13 brass male contacts with tin plating for corrosion resistance. Durable nylon housing for electrical insulation and mechanical strength. Through-hole solder termination provides secure PCB mounting. Rated for 3A current and 250V voltage.

Operates between -40°C to 105°C temperature range. Unshrouded, straight orientation for easy access and connection. Friction locking ramp guarantees secure mating. Compatible with Mini-Latch and KK series crimp housings.

This pin header is well-suited for industrial, automotive, communications, and electronic manufacturing applications demanding secure, reliable wire-to-board connectivity. Its robust design ensures long-lasting performance even under demanding environmental conditions. Explore similar high-quality PCB Headers available in EnvMart’s Electronics & Electricals catalog to find complementary components for your projects.
