Molex SL Series Right Angle Through Hole PCB Header, 6 Contacts, 2.54 mm Pitch, 1 Row, Shrouded 70553-0005

Free Delivery in India | Lowest Global Shipping Charges

Molex SL Series Right Angle Through Hole PCB Header, 6 Contacts, 2.54 mm Pitch, 1 Row, Shrouded 70553-0005

Name: Molex SL Series Right Angle Through Hole PCB Header, 6 Contacts, 2.54 mm Pitch, 1 Row, Shrouded 70553-0005
Brand: Molex
SKU: 209095
Price: 2.5 USD
Availability: InStock



Category PCB Header Brand Molex Condition New

Specifications

Country of Origin	India
Voltage	250V
Brand	Molex
Orientation	Right Angle
Current	3A
Mount Type	Through Hole
Housing Material	Thermoplastic
Contact Material	Phosphor Bronze
Series	SL
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Number of Rows	1
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	6
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board
Tail Pin Length	3.3mm
Mating Pin Length	6.1mm

Key Features

Made with thermoplastic housing to ensure durability.
Right angle orientation enables compact PCB mounting.
Gold-plated phosphor bronze contacts for excellent conductivity.
Supports a current rating of 3 amperes.
Operates within temperature range from -40°C to 105°C.
Tail pin length is 3.3 mm with mating pin length of 6.1 mm.
Designed for solder termination with through-hole mount type.
Compatible with Molex 70066G and 70066N series housings.

Product Description

Molex 70553-0005 SL Series Right Angle Through Hole PCB Header is designed for wire-to-board connectivity in electronic assemblies, featuring 6 gold-plated contacts arranged in a single row with a 2.54 mm pitch.

The connector's thermoplastic housing provides robustness and insulation, while the shrouded design protects mating pins and improves alignment during insertion. The right-angle orientation facilitates dense PCB layouts by redirecting connections sideways.

This PCB header supports a maximum current of 3 amperes and a voltage rating of 250 volts, making it suitable for industrial, electronic, and manufacturing applications requiring reliable signal and power transmission.

The contact material is phosphor bronze with gold plating of 0.38 μm thickness, ensuring corrosion resistance and stable electrical performance. Operating temperature ranges from -40°C up to 105°C, supporting harsh environments.

The tail pin length is 3.3 mm and mating pin length is 6.1 mm for secure, soldered through-hole mounting. It mates with Molex 70066G and 70066N series housings, providing versatile system integration.

This header is ideal for industrial, commercial electronics manufacturing, prototyping, and repair tasks. Durable thermoplastic housing for protection and insulation. Right angle orientation for space-efficient PCB designs.

Gold-plated phosphor bronze contacts ensure excellent conductivity and durability. High current rating supporting up to 3A for reliable power connections. Wide temperature operation from -40°C to 105°C guarantees performance in various settings.

Solder termination type with through-hole mount for strong mechanical and electrical connection. Compatible with Molex 70066G and 70066N housings for flexible assembly options. Voltage rating up to 250V enhances safety and standards compliance.

Explore a broad range of connectors and PCB Headers in the Electronics & Electricals category on EnvMart for dependable components tailored to industrial and commercial applications.
