onsemi Bridge Rectifier 100 V 50 A 4-Pin Single Surface Mount SDIP Package DF01S

onsemi DF01S Bridge Rectifier is a high-performance discrete semiconductor device designed for efficient AC to DC conversion in electrical circuits. It features a surface mount SDIP package suitable for automated PCB assembly processes. Rated for a peak reverse repetitive voltage of 100 V and a forward surge current of 50 A, this device supports robust operation in demanding environments.

Constructed with a glass passivated chip junction, the DF01S ensures low DC reverse current, reducing leakage and enhancing overall efficiency. Its compact dimensions - 8.51 mm in length, 6.5 mm in width, and 3.3 mm in height - allow it to fit into densely packed electronic assemblies. The device is designed for single-phase applications and includes four pins for reliable electrical connection.

Operating temperature ranges from -55°C to a maximum of 150°C, accommodating a wide range of industrial, laboratory, and commercial electronic uses. The peak forward voltage of 1.1 V minimizes power dissipation during forward conduction, making it ideal for power management circuits. This bridge rectifier does not comply with automotive standards but complies with UL file E111753 and E326243 certifications, reflecting quality manufacturing processes.

The DF01S bridge rectifier by onsemi is part of the DF-S series, widely used in power supplies, inverters, and other semiconducting circuits requiring efficient and reliable rectification of AC signals into DC output. Its surface mount design improves manufacturing efficiency and device integration in modern electronics.

Features low DC reverse current for efficient rectification. Operates reliably up to a maximum temperature of 150°C. Compact dimensions of 8.51 mm length, 6.5 mm width, and 3.3 mm height. Designed for single-phase configuration with a 4-pin count.

Compatible with surface mount technology for PCB applications. Includes glass passivated chip junction for stability. Peak forward voltage is 1.1 V ensuring low power loss. Minimum operating temperature is -55°C for wide environmental resistance.

Compliant with UL file E111753 and E326243 approvals. Part of the DF-S series providing reliable bridge rectifier solutions.

This bridge rectifier is essential for applications in industrial electronics, power supply units, laboratory instrumentation, HVAC systems, and manufacturing equipment requiring AC/DC conversion. Its robust build and trusted reliability from onsemi make it an optimal choice for engineers and designers.
