Molex 26-Way IDC Connector Male for Surface Mount, 1 Row, 1.2A, 250V, 1.27mm Pitch 90814-0826

Molex 90814-0826 is a 26-Way IDC Connector Male designed for surface mounting in electronic applications. It features a single row of 26 contacts with a 1.27 mm pitch and supports a current rating of 1.2A and voltage rating of 250V AC. The connector uses brass contacts plated with tin over nickel to ensure reliable electrical performance.

The housing is made from durable nylon material, providing insulation and mechanical robustness. This unshrouded male connector is oriented straight and is terminated via IDC, suitable for fast and secure connections to flat ribbon cables in low profile Picoflex wire-to-board applications.

Operating temperatures range from -40°C up to 105°C, allowing use in demanding industrial, automotive, and consumer electronic environments. The connector is part of the Picoflex series, which offers substantial space savings of 50% compared to traditional pitches and includes excellent polarization features, integral strain relief, and high resistance to vibration and shock.

Additional product highlights include friction lock and stamped contacts with inline flat tabs, ensuring secure mating and reliable performance. The Picoflex IDT connectors are pre-terminated cable assemblies available and suited for high-density applications where standard flat flexible or discrete wire connectors are less optimal.

Compliance with UL and CSA standards underscores its suitability for industrial and commercial use cases. Manufactured in Ireland, this connector guarantees quality and consistency.

Features 26 male contacts arranged in a single row for efficient surface mounting. Constructed with brass contact material plated with tin over nickel for reliable connectivity. Housing made of durable nylon ensuring insulation and mechanical stability.

Operating temperature range from -40°C to 105°C suitable for various environments. Unshrouded connector with straight orientation for easy IDC termination. Designed as part of the Picoflex series for low profile 1.27 mm wire to board applications.

Ideal for automotive and consumer electronics where space saving and vibration resistance are important. Fitted with friction lock, polarization, and stamped contacts with inline flat tabs for secure connections. Complies with UL (E29179) and CSA (LR19980-181) approvals, ensuring quality standards.

Manufactured in Ireland, ensuring high production quality. For more high-quality connector components, browse the Electronics & Electricals section of EnvMart.
