Molex Micro-Fit 3.0 Series Straight Through Hole PCB Header 3 Contact 3 mm Pitch 1 Row Shrouded 43650-0316
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Molex |
| Orientation | Straight |
| Current | 5A |
| Mount Type | Through Hole |
| Housing Material | Thermoplastic |
| Contact Material | Brass |
| Series | Micro-Fit 3.0 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 3mm |
| Contact Plating | Gold |
| Number of Contacts | 3 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- This PCB header supports a current rating of 5A for reliable electrical performance.
- Constructed with thermoplastic housing capable of withstanding up to 105°C operating temperature.
- Features gold-plated brass contacts and positive latching for secure mating.
- Designed with PCB polarizing pegs and kinked solder legs for improved alignment and retention.
- Suitable for wire-to-board connection systems in low to mid power applications.
- The single row connector supports a voltage rating up to 250V.
- Compatible with surface mount technology (SMT) and through hole mounting.
- Manufactured with high temperature UL 94V-0 liquid crystal polymer for IR reflow soldering tolerance.
Product Description
Molex 43650-0316 Micro-Fit 3.0 Series Straight Through Hole PCB Header is a single row, shrouded connector designed for wire-to-board applications with a 3 mm pitch and 3 contacts. This connector series offers a compact power distribution solution with high current carrying capacity up to 5A in a small footprint.
Constructed with a thermoplastic housing rated to operate between -40°C to 105°C, it ensures durability in demanding environments. The gold-plated brass contacts provide reliable electrical connectivity and corrosion resistance. Additionally, positive latching with a locking ramp on the housing prevents accidental disconnections during use.
The connector incorporates PCB polarizing pegs for precise alignment and positioning on the PCB. Models with suffixes ending in xx15, xx16, and xx17 feature kinked solder legs for enhanced PCB retention. The through hole mounting design is SMT compatible, reducing manufacturing process costs and complexity.
This Micro-Fit 3.0 header is suitable for a wide range of applications including military commercial off-the-shelf (COTS) systems, solar power, consumer appliances like dryers and refrigerators, data communications equipment such as routers and servers, medical devices, telecommunications, and gaming terminals.
High current capacity in a compact connector footprint. Thermoplastic housing with UL 94V-0 rating for IR reflow soldering up to 265°C. Fully isolated dual beam terminals increase reliability and reduce arcing. Positive latching mechanism ensures secure mating connection.
PCB polarizing pegs and kinked solder legs aid alignment and retention on board. Durable gold-plated brass contacts prevent corrosion. Compatible with through hole and surface mount technology processes.
Choose Molex Micro-Fit 3.0 Series connectors for robust and compact PCB header solutions in industrial, telecommunications, medical, consumer electronics, and power distribution sectors. Explore the complete range of PCB connectors and wire housings for your electronic component needs on EnvMart.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a current rating of 5A for reliable electrical performance.
The voltage rating is up to 250V.
It features a thermoplastic housing and brass contacts, with gold plating for the contacts.
The operating temperature range is from -40°C to 105°C.
This model has 3 contacts.
It supports through hole mounting and is also compatible with surface mount technology (SMT).
The pitch size is 3 mm.
Yes, it includes a positive latching mechanism for secure mating connections.
It is suitable for wire-to-board connection systems in low to mid power applications, including military, telecommunications, and consumer electronics.
The orientation is straight.
It uses solder termination.
The country of origin for this PCB header is India.
