Molex C-Grid III Series Straight Through Hole PCB Header, 18 Contact(s), 2.54 mm Pitch, 2 Row, Shrouded 90130-1218

Molex 90130-1218 C-Grid III Series PCB Header is a high-quality, straight through hole mounting connector designed for electronic circuits requiring reliable wire-to-board connections. Featuring 18 male contacts arranged in two rows with a 2.54 mm pitch, this shrouded header provides secure and precise mating with compatible locking housings.

The housing is made from durable polyester material, delivering excellent electrical insulation and mechanical robustness suitable for industrial and commercial electronic applications. Gold-plated brass contacts provide low resistance and superior conductivity while ensuring resistance to corrosion over prolonged use.

This PCB header is rated for a maximum operating voltage of 350 V and current of 3 A, making it suitable for a wide range of control, automation, and circuit board interconnection purposes. It supports an operating temperature range from -55°C up to 125°C, enabling use in harsh and temperature-variable environments.

The through-hole mount and solder termination type facilitate easy integration into printed circuit boards, ensuring reliable mechanical and electrical connections. Tail pins measure 2.9 mm in length, and the mating pin length is 6.75 mm to assure compatibility and secure locking with mating connectors.

This product complies with no specific standards or approvals listed but is ideal for industrial electronics, telecommunications, consumer electronics, instrumentation, and manufacturing applications.

Constructed with polyester housing for durability and insulation. Compatible with wire-to-board connector system. Gold-plated brass contacts ensure reliable conductivity. Supports operating temperatures from -55°C to 125°C.

Rated for 350 Volts and 3 Amps of current capacity. Designed for through-hole mounting with solder termination. Locking header suitable for use with compatible locking housings. Tail pin length of 2.9 mm and mating pin length of 6.75 mm.

Shrouded to provide protection and precise alignment of connections.

This Molex PCB Header is a trusted component across various electronic design and manufacturing sectors. Explore similar Molex connectors and PCB header solutions in the Electronics & Electricals category at EnvMart for comprehensive project needs.
