Molex C-Grid Series Straight Through Hole PCB Header, 40 Contacts, 2.54 mm Pitch, 2 Row, Shrouded 70246-4001

Molex 70246-4001 C-Grid Series Straight Through Hole PCB Header is engineered for reliable wire-to-board connections with 40 contacts in a 2-row configuration and 2.54 mm pitch spacing. Its shrouded design safeguards the contacts during handling and assembly while ensuring stable mechanical and electrical performance.

The housing made from Polybutylene Terephthalate provides excellent temperature resistance and mechanical strength. Contacts are crafted from phosphor bronze and plated with gold for high conductivity and corrosion resistance, ideal for industrial and commercial electronics.

This 70246-4001 header features a solder termination and through hole mount style for secure PCB integration and mechanical stability. It is rated for a current of 2.5 A and voltage up to 250 V, making it suitable for applications requiring dependable power delivery and signal integrity.

With a broad operating temperature range from -55°C to 120°C, this header performs reliably in harsh and varying environmental conditions common in industrial equipment, laboratory instruments, manufacturing machinery, and commercial electronics assemblies.

Additional features include a contact tail pin length of 3.43 mm and mating pin length of 2.54 mm, ensuring precise alignment and connectivity. The straight, shrouded orientation facilitates easy insertion and protection against damage.

Supports a current rating of 2.5 A per contact for robust electrical performance. Durable Polybutylene Terephthalate housing ensures mechanical strength and thermal resistance. Phosphor bronze contacts with gold plating provide excellent durability and conductivity.

Solder termination and through hole mount type enable firm PCB connections. Wide temperature operating range from -55°C to 120°C meets rigorous industrial requirements. Contact tail pin length of 3.43 mm and mating pin length of 2.54 mm ensure precise mating.

Voltage rating of 250 V suitable for varied electrical applications. Shrouded design protects contacts and improves safety during assembly.

This PCB header is suitable for use in electronics manufacturing, industrial machinery controls, telecommunications equipment, and automotive electronics. Its reliable electrical and mechanical properties support demanding operational conditions.
