Molex KK 508 Series Straight Through Hole Pin Header, 7 Contacts, 5.08 mm Pitch, 1 Row, Unshrouded 10-08-1071

Free Delivery in India | Lowest Global Shipping Charges

Molex KK 508 Series Straight Through Hole Pin Header, 7 Contacts, 5.08 mm Pitch, 1 Row, Unshrouded 10-08-1071

Name: Molex KK 508 Series Straight Through Hole Pin Header, 7 Contacts, 5.08 mm Pitch, 1 Row, Unshrouded 10-08-1071
Brand: Molex
SKU: 206393
Price: 1.25 USD
Availability: InStock



Category PCB Headers Brand Molex Condition New

Specifications

Country of Origin	India
Voltage	250V
Brand	Molex
Orientation	Straight
Current	7A
Mount Type	Through Hole
Housing Material	Nylon
Contact Material	Brass
Series	KK 508
Termination Type	Solder
Maximum Operating Temperature	80°C
Minimum Operating Temperature	-40°C
Number of Rows	1
Pitch	5.08mm
Contact Plating	Tin
Number of Contacts	7
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded
Connector System	Board-to-Board, Wire-to-Board
Tail Pin Length	3.94mm

Key Features

This unshrouded pin header is built with brass contacts plated in tin for reliable conductivity.
The housing is constructed from durable nylon, ensuring stability and insulation.
Supports up to 7 amperes current and operates at a voltage rating of 250V.
Designed for through-hole mounting on PCBs with a termination style suitable for soldering.
Operating temperature ranges from -40°C to a maximum of 80°C for reliable performance.
Specifically engineered for board-to-board and wire-to-board connector systems.
Tail pin length measures 3.94 mm, compatible with 3001, 5058, and 3002 series housings and connectors.

Product Description

Molex 10-08-1071 KK 508 Series Straight Through Hole Pin Header features 7 male contacts arranged in a single row with a 5.08 mm pitch, designed for reliable board-to-board and wire-to-board connections.

The contacts are made of brass and plated with tin to ensure excellent electrical conductivity and resistance to corrosion. The housing material is high-quality nylon, providing robust mechanical support and insulation.

This unshrouded connector supports a current rating of 7A and voltage rating of 250V, suitable for various electronic applications including industrial, commercial, and manufacturing environments.

The pin header has a tail pin length of 3.94 mm and uses solder termination for secure mounting on printed circuit boards. It offers a minimum operating temperature of -40°C and maximum of 80°C, ensuring dependable operation across temperature extremes.

Brass male contacts plated with tin for superior conductivity. Durable nylon housing providing insulation and mechanical strength. 5.08 mm pitch, single-row configuration for standard PCB layouts. Supports up to 7A current and 250V voltage for diverse applications.

Designed for through-hole solder mounting for robust connectivity. Compatible with 3001, 5058, and 3002 series housings and connectors. Wide operating temperature range from -40°C to 80°C.

This pin header is ideal for use in electronic component assemblies, PCB designs, and industrial control equipment requiring dependable interconnection solutions. Its unshrouded design facilitates easy inspection and testing.

Molex is renowned for engineering high-quality connectors designed to meet demanding industrial and electronic application requirements. This 10-08-1071 model provides an economical and practical solution for effective wire-to-board and board-to-board connections ensuring long-term durability.

For buyers seeking reliable PCB connectors that balance performance with cost-efficiency, the KK 508 Series 10-08-1071 pin header from Molex offers an excellent choice. Explore a wide range of compatible accessories and components on EnvMart for comprehensive interconnection solutions.
