Vishay 100 V 2 A Schottky Barrier Diode Surface Mount DO-221AD VSS8D2M10HM3/H
Specifications
| Country of Origin | China |
|---|---|
| Brand | Vishay |
| Height | 2.7mm |
| Length | 5mm |
| Model | VSS8D2M10HM3/H |
| Mount Type | Surface |
| Series | VSS8D2M10 |
| Maximum Operating Temperature | 175°C |
| Package Type | DO-221AD |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 2A |
| Peak Reverse Repetitive Voltage Vrrm | 100V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Non-Repetitive Forward Surge Current Ifsm | 50A |
| Maximum Forward Voltage Vf | 0.56V |
Key Features
- Features low forward voltage drop of 0.56 V to minimize power loss.
- Capable of continuous forward current of 2 A and peak surge current of 50 A.
- Temperature operating range spans from -40°C to 175°C for reliable performance.
- Packaged in compact DO-221AD surface mount package with 2 pins and 5 mm length.
- Meets RoHS compliance and automotive standard AEC-Q101 for automotive applications.
- Ideal for use in high-frequency inverters, freewheeling, DC/DC converters, and polarity protection.
- Designed to deliver fast switching speeds with low leakage current.
- Manufactured in China ensuring adherence to quality standards.
Product Description
Vishay VSS8D2M10HM3/H is a high-performance Schottky barrier diode designed for electronic applications requiring fast switching and low forward voltage drop. This surface mount diode packaged in DO-221AD housing offers a maximum continuous forward current of 2 A and peak reverse voltage of 100 V, making it well suited for commercial, industrial, and automotive semiconductor projects.
The diode is engineered with a Trench MOS Barrier Schottky construction that provides low forward voltage (0.56 V) to reduce power dissipation and increase efficiency in circuits. Its reliable operation is ensured across a temperature range from -40°C up to 175°C.
Its compact 2-pin DO-221AD package with dimensions of 5 mm length and 2.7 mm height supports surface mounting for automated assembly. This device complies with RoHS directives and the AEC-Q101 automotive standard, denoting suitability for automotive electronic use cases involving high-frequency inverters, freewheeling diodes, DC/DC converters, and polarity protection circuits.
Low forward voltage drop of 0.56 V reduces power loss. Maximum continuous forward current of 2 A ensures reliable conduction. Peak surge current rating of 50 A for transient handling. Operating temperature range from -40°C to 175°C supports harsh conditions.
Compact DO-221AD surface mount package with 2 pins enables automated PCB assembly. RoHS compliant and meets AEC-Q101 automotive standard. Ideal for use in industrial, automotive, power supply, and semiconductor applications.
Manufactured in China ensuring consistent quality control.
This Vishay Schottky diode facilitates efficient electronic design with low power loss and high temperature tolerance. It is recommended for integration in power management, inverter, and converter circuits across industrial and automotive electronics.
Explore more Schottky Diodes and semiconductor components in the Electronics & Electricals category at EnvMart for your industrial and electrical engineering needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of this model is 2 A.
The peak reverse voltage rating for this diode is 100 V.
This Schottky diode has a maximum forward voltage drop of 0.56 V.
The operating temperature range for this diode spans from -40°C to 175°C.
It is packaged in a compact DO-221AD surface mount package.
This model features a 2-pin configuration.
The peak surge current rating is 50 A.
Yes, it meets the AEC-Q101 automotive standard.
The dimensions of the DO-221AD package are 5 mm in length and 2.7 mm in height.
This diode is ideal for use in high-frequency inverters, freewheeling applications, DC/DC converters, and polarity protection.
It is manufactured in China, ensuring adherence to quality standards.
This diode complies with RoHS directives.
