TDK Shielded Wirewound Surface Mount Inductor with Ferrite Core 1μH ±30% 12A Maximum DC Current VLS6045EX-1R0N-H

Free Delivery in India | Lowest Global Shipping Charges

TDK Shielded Wirewound Surface Mount Inductor with Ferrite Core 1μH ±30% 12A Maximum DC Current VLS6045EX-1R0N-H



Category Inductor Brand TDK Condition New

Specifications

Country of Origin	Korea
Brand	TDK
Height	4.5mm
Length	6mm
Model	VLS6045EX-1R0N-H
Depth	6.3mm
Packaging	Tape & Reel
Series	VLS-EX-H
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Core Material	Ferrite
Inductance	1μH
Standards/Approvals	RoHS
Package/Case	6045
Maximum DC Current	12A
Maximum DC Resistance	16mΩ
Inductance Tolerance	±30 %
Termination Style	Surface Mount
Inductor Construction	Shielded
Automotive Standard	AEC-Q200

Key Features

Compact 6045 package size with dimensions 6mm length, 4.5mm height, and 6.3mm depth.
Magnetic shield construction using ferrite magnetic material for high-density power circuit mounting.
Maximum DC resistance of 16 milliohms for efficient current handling.
Operates reliably within temperature range of -40°C to 125°C.
Complies with automotive standard AEC-Q200 and RoHS directives for quality and environmental compliance.
Delivered in tape and reel packaging to support automated assembly processes.
Designed for surface mount technology (SMT) with shielded wirewound inductor construction.
Manufactured in Korea, Republic Of ensuring consistent manufacturing quality.

Product Description

TDK VLS6045EX-1R0N-H is a high-performance shielded wirewound surface mount inductor featuring a ferrite core and designed for demanding power circuit applications. With an inductance of 1μH and an inductance tolerance of ±30%, this inductor offers consistent electrical characteristics suitable for industrial and automotive electronics.

The component is built in a 6045 package with physical dimensions of 6mm length, 4.5mm height, and 6.3mm depth, allowing compact and space-efficient PCB layout. The ferrite core and magnetic shield reduce electromagnetic interference, making this inductor ideal for high-density mounting in power conversion circuits and filtering applications.

Rated for a maximum DC current of 12A and maximum DC resistance of just 16 milliohms, the VLS6045EX-1R0N-H supports high current loads while minimizing power loss and heat generation. It operates reliably in temperature conditions ranging from -40°C to 125°C, meeting stringent automotive standard AEC-Q200 and environmental requirements with RoHS compliance.

Packaging is supplied as tape and reel for streamlined surface mount technology (SMT) manufacturing processes. This product is manufactured in Korea, Republic Of, ensuring quality and reliability that meets industrial standards.

Compact 6045 SMT package for space-saving PCB designs. Ferrite core magnetic shield construction reduces interference. High current rating of 12A maximizes performance for power circuits. Low DC resistance minimizes energy loss and heat.

Wide operating temperature range from -40°C to 125°C. Compliance with AEC-Q200 automotive standard ensures ruggedness. RoHS compliant for environmentally safe use. Tape and reel packaging supports automated PCB assembly.

This TDK inductor series is suitable for industrial, automotive, telecommunications, and power management applications requiring robust performance and compact mounting solutions. Explore the Electronics Components category on EnvMart for similar high-quality Inductors and passive components.
