Bourns 3015 Shielded Surface Mount Inductor 22 μH ±20% 600 mA Idc Ferrite Core SRN3015

Free Delivery in India | Lowest Global Shipping Charges

Bourns 3015 Shielded Surface Mount Inductor 22 μH ±20% 600 mA Idc Ferrite Core SRN3015

Name: Bourns 3015 Shielded Surface Mount Inductor 22 μH ±20% 600 mA Idc Ferrite Core SRN3015
Brand: BOURNS
SKU: 129372
Price: 0.3 USD
Availability: InStock



Category Inductor Brand BOURNS Condition New

Specifications

Country of Origin	India
Brand	Bourns
Height	1.5mm
Length	3mm
Model	SRN3015
Depth	3mm
Packaging	Reel
Series	SRN3015
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Core Material	Ferrite
Inductance	22μH
Standards/Approvals	RoHS
Package/Case	3015
Maximum DC Current	600mA
Maximum DC Resistance	622mΩ
Inductance Tolerance	±20 %
Termination Style	Solder
Maximum Self Resonant Frequency	28MHz
Minimum Quality Factor	26
Inductor Construction	Semi Shielded
Automotive systems	Driver assistant, information, lighting, entertainment

Key Features

Inductance of 22 microhenries with ±20% tolerance.
Maximum DC current rating of 600 mA for reliable performance.
Compact 3015 package size with 3 mm length and 1.5 mm height.
Ferrite core material providing efficient magnetic shielding.
Operating temperature range from -40°C to 125°C.
Maximum DC resistance of 622 milliohms to minimize losses.
Solder termination style designed for surface mount PCB assembly.
Maximum self-resonant frequency of 28 MHz suitable for high-frequency applications.

Product Description

Bourns SRN3015-220M is a high-quality shielded surface mount inductor featuring a 22 μH inductance with a ±20% tolerance, designed for efficient power management in electronic circuits. This semi-shielded inductor incorporates a ferrite core that enhances magnetic performance and minimizes electromagnetic interference.

The inductor is housed in a compact 3015 package measuring 3 mm in length, 3 mm in depth, and 1.5 mm in height, making it ideal for dense surface mount applications. It supports a maximum DC current of 600 mA and operates within a temperature range of -40°C to 125°C, ensuring durability under diverse environmental conditions.

With a maximum DC resistance of 622 mΩ and a minimum quality factor of 26, the SRN3015-220M delivers efficient energy storage with low losses. The component has a maximum self-resonant frequency of 28 MHz that makes it suitable for high-frequency switching power supplies and DC-DC converter circuits.

This semi-shielded wire wound inductor is RoHS compliant, mold encapsulated, and features solder terminations designed for optimized surface mounting on PCBs. Its application areas include automotive systems such as driver assistance, information display, lighting, and entertainment, as well as power supplies, televisions, and digital video equipment.

Inductance of 22 microhenries with ±20% tolerance. Maximum DC current rating of 600 mA for reliable performance. Compact 3015 package size with 3 mm length and 1.5 mm height. Ferrite core material providing efficient magnetic shielding.

Operating temperature range from -40°C to 125°C. Maximum DC resistance of 622 milliohms to minimize losses. Solder termination style designed for surface mount PCB assembly. Maximum self-resonant frequency of 28 MHz suitable for high-frequency applications.

This Bourns SRN3015 series inductor is ideal for industrial, automotive, and consumer electronics, supporting reliable power management and signal conditioning. Explore a wide range of Inductor solutions on EnvMart for your electronic component needs.
