Bourns 4026 Shielded Wirewound Surface Mount Inductor with Ferrite Core 100μH ±20% 300mA Idc Q:30 SRN4026
Specifications
| Country of Origin | India |
|---|---|
| Brand | Bourns |
| Height | 2.5mm |
| Length | 4mm |
| Model | SRN4026 |
| Depth | 4mm |
| Packaging | Reel |
| Series | SRN4026 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance Range | 1 to 220 μH |
| Inductance | 100μH |
| Standards/Approvals | RoHS |
| Package/Case | 4026 |
| Maximum DC Current | 300mA |
| Pin Count | 2 |
| Maximum DC Resistance | 1200mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Solder |
| Maximum Self Resonant Frequency | 7MHz |
| Minimum Quality Factor | 30 |
| Inductor Construction | Wirewound |
Key Features
- Rated for a maximum DC current of 300 mA.
- Constructed with wirewound technology and semi-magnetic shielding.
- Compact 4026 package size with 4mm length and 2.5mm height.
- Maximum DC resistance of 1200 mΩ ensures efficient operation.
- Suitable for DC/DC converters and various electronic applications.
- Operating temperature range from -40°C to 125°C.
- RoHS compliant and moulded for durability.
- Contains 2 pins and solder termination style for PCB mounting.
Product Description
Bourns SRN4026 shielded wirewound surface mount inductor with ferrite core offers 100μH inductance with ±20% tolerance and a rated maximum DC current of 300 mA. The SRN4026 series features semi-magnetic shielding and compact 4026 package dimensions, measuring 4 mm length, 4 mm depth, and 2.5 mm height. It is designed for high-performance applications where space and reliability are crucial.
This wirewound inductor incorporates a ferrite core for efficient energy storage and reduced electromagnetic interference. It supports a maximum DC resistance of 1200 mΩ to ensure minimal power loss during operation. The product meets RoHS standards and is moulded for mechanical stability.
Operating within a temperature range of -40°C to 125°C, this inductor is suitable for industrial and consumer electronic uses including DC/DC converters, notebook computers, digital video cameras, hard disk drives, cellphones, televisions, and LCD displays. The solder termination style and 2-pin configuration allow easy and secure PCB assembly.
Rated for a maximum DC current of 300 mA. Compact 4026 package with dimensions 4 x 4 x 2.5 mm. Semi-shielded construction reduces electromagnetic interference. Ferrite core for enhanced magnetic performance. Wirewound construction for durability and stable inductance.
RoHS compliant, meeting environmental standards. Maximum self-resonant frequency of 7 MHz and minimum quality factor of 30. Suitable for use in DC/DC converters and portable devices.
These inductors support high reliability and performance in demanding electronic applications across industrial, commercial, and consumer sectors. Ideal for manufacturers and designers seeking a reliable shielded surface mount solution.
Explore more precision electronic components and Inductors at EnvMart for your design and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 100μH with a tolerance of ±20%.
It is rated for a maximum DC current of 300 mA.
The dimensions of the 4026 package are 4 mm in length, 4 mm in depth, and 2.5 mm in height.
The maximum DC resistance is 1200 mΩ, ensuring efficient operation.
The operating temperature range is from -40°C to 125°C.
This inductor uses a ferrite core for enhanced magnetic performance.
The termination style is solder, featuring a 2-pin configuration for PCB mounting.
The maximum self-resonant frequency is 7 MHz.
The minimum quality factor is 30.
Yes, this inductor is RoHS compliant, meeting environmental standards.
This inductor is packaged in a reel format.
