DiodesZetex Darlington Transistor NPN 2 A 140 V 3 W SOT-223 4-Pin FZT600TA

DiodesZetex FZT600TA is a high-performance NPN Darlington transistor designed for discrete semiconductor applications that require efficient current amplification and reliable switching capabilities. Featuring a maximum continuous collector current (Ic) of 2 A and a collector emitter voltage (Vceo) of 140 V, this transistor is ideal for use in power amplification circuits, automotive electronics, and industrial control systems.

The device comes in a compact SOT-223 surface mount package with 4 pins, providing ease of integration onto printed circuit boards while ensuring thermal efficiency through a power dissipation rating of 3 W. The high DC current gain (hFE) of 1000 maximizes signal amplification, making it suitable for circuits where strong gain is necessary.

Operating reliably over a temperature range of -55°C to 150°C, the FZT600TA meets the stringent AEC-Q101 automotive standard, confirming its suitability for automotive and other demanding environments. Its maximum emitter base voltage (VEBO) of 10 V and collector base voltage (VCBO) of 160 V further enhance its robustness in various applications.

The sensitive low cut-off collector current of 0.00001 mA ensures minimal leakage, contributing to energy-efficient circuit design. With physical dimensions of 6.55 mm length and 1.65 mm height, the transistor fits well into compact electronic assemblies requiring durable and reliable semiconductor components.

Maximum continuous collector current of 2 A supports moderate power applications. Collector emitter voltage rated at 140 V ensures reliable switching performance. High DC current gain (hFE) of 1000 optimizes amplification efficiency.

Surface mount SOT-223 package enables compact board layouts. Wide operating temperature range (-55°C to 150°C) suits harsh conditions. Power dissipation rating of 3 W for stable heat management. Automotive standard AEC-Q101 assures quality and reliability.

Pin count of 4 facilitates easy connection in circuitry. Compact size of 6.55 mm length and 1.65 mm height.

This Darlington Transistor is widely used in electronic components for power regulation, amplification, switching circuits, automotive systems, and industrial controls. It supports efficient design in consumer electronics, manufacturing equipment, and various engineering applications. Opt for this robust and versatile component to enhance circuit performance and reliability.
