STMicroelectronics Darlington Transistor PNP 2 A 60 V TO-220 Package TIP115

STMicroelectronics TIP115 is a PNP Darlington transistor designed to handle a maximum continuous collector current of 2 A and a collector emitter voltage of up to 60 V encapsulated in a TO-220 package. This transistor features a high minimum DC current gain (hFE) of 500, ensuring efficient signal amplification for demanding industrial and electronic applications.

Its robust thermal rating allows for a maximum power dissipation of 50 W, making it suitable for power switching and amplification tasks in industrial, manufacturing, consumer electronics, and automotive systems that require reliable performance over a wide temperature range from -65°C to 150°C.

The TO-220 through hole package with 3 pins facilitates easy mounting and integration into existing PCB layouts. Its electrical properties include a maximum collector emitter saturation voltage of 2.5 V and maximum emitter base voltage of 5 V, contributing to reduced power losses and improved efficiency.

This discrete semiconductor device contains a single transistor element per chip and does not have any specific automotive certification but is widely used across general-purpose power transistor applications.

Typical use cases include power drivers, relay drivers, output stages in audio and switching power supplies, and other applications where a high gain transistor is required. The transistor's compact size combined with high performance makes it an essential component in many industrial and electronic circuitry designs.

PNP Darlington transistor with 2 A maximum collector current. 60 V maximum collector emitter voltage. High current gain with 500 minimum hFE. Power dissipation of 50 W to handle significant load. TO-220 package for through-hole mounting.

Wide operating temperature from -65°C to 150°C. Designed for general purpose power switching and amplification. Single transistor element in discrete semiconductor format. No specific automotive certification. This product is part of the STMicroelectronics Bipolar Transistors series and is suitable for electronic components categories dealing with discrete power semiconductors.
