onsemi PNP Darlington Transistor TO-220 8A 100V 80W 3-Pin TIP107G

onsemi TIP107G is a PNP Darlington transistor designed for high current and voltage applications. It features a maximum continuous collector current of 8 amperes and a collector-emitter voltage rating of 100 volts, making it suitable for various power switching and amplification roles. Packaged in a TO-220 form factor with three pins, it supports through-hole mounting for easy assembly.

This transistor provides a minimum DC current gain (hFE) of 200, enabling efficient signal amplification while handling power dissipation up to 80 watts. Its PNP polarity is ideal for complementary circuits requiring precise control.

The device operates reliably over a broad temperature range from -65°C to 150°C, ensuring consistent performance in industrial, laboratory, and electronic manufacturing contexts. Its compact physical size allows integration in space-constrained PCB designs.

With a maximum emitter-base voltage of 5 volts and maximum collector-base voltage also at 100 volts, it supports robust operation in demanding environments. The low collector cutoff current of 0.05 mA further optimizes switching performance.

Package details include a durable TO-220 casing, widely recognized in electronic components for heat dissipation and mount stability. Applications include use in power amplifiers, motor controllers, relays, and other industrial electronic circuits.

Maximum continuous collector current of 8 amperes ensures robust performance. Collector-emitter voltage rating of 100 volts for versatile applications. High current gain (hFE) of at least 200 for efficient amplification.

Power dissipation capability up to 80 watts supports demanding loads. Through-hole mount type with a 3-pin TO-220 package for easy PCB integration. Suitable for use in power switching and amplification circuits. Operating temperature range from -65°C to 150°C ensures reliability in harsh conditions.

PNP polarity Darlington transistor for precise electronic control. Compact dimensions of approximately 10.28 mm length and 9.28 mm height. Designed for industrial and electronic component applications. Explore more semiconductor components and Darlington Transistors in the Electronics category at EnvMart.
