onsemi 1 2-Input AND Logic Gate, 5-Pin TSOP MC74VHC1G09DTT1G

onsemi MC74VHC1G09DTT1G is a 1 2-Input AND Logic Gate designed with high-speed silicon-gate CMOS technology, delivering advanced performance for electronic and industrial applications. The device is housed in a compact 5-pin TSOP surface mount package which facilitates efficient circuit board space usage and supports automated manufacturing processes.

This logic gate operates over a wide voltage range from 2.0 to 5.5 volts and supports operating temperatures from -55°C to 125°C, suitable for diverse environmental conditions including automotive and industrial environments. It features a maximum propagation delay of 5.8 nanoseconds, ensuring swift signal processing in timing-critical circuits.

The MC74VHC1G09DTT1G belongs to the VHC logic family and comes with CMOS input type and an open drain output type, suitable for varied digital logic designs. It complies with RoHS and Pb-Free standards, reflecting its environmentally safe manufacturing processes. Additionally, the device meets the stringent AEC-Q100 automotive standard certification, endorsing its reliability for automotive electronic designs.

This product is ideal for applications in industrial automation, embedded system development, signal processing, and other electronic design projects requiring compact and reliable logic components.

Advanced high-speed low-power CMOS logic technology. Single-gate package for compact circuit design. Wide operating temperature range from -55°C to 125°C. Maximum propagation delay time of 5.8 nanoseconds. Surface mount 5-pin TSOP package.

Compliant with RoHS and Pb-Free environmental standards. Certified to AEC-Q100 automotive standard. Operating voltage range of 2.0 to 5.5 volts.
