onsemi 1 2-Input AND Logic Gate CMOS Surface Mount SC-70 5-Pin NC7SV08P5X

Free Delivery in India | Lowest Global Shipping Charges

onsemi 1 2-Input AND Logic Gate CMOS Surface Mount SC-70 5-Pin NC7SV08P5X

Name: onsemi 1 2-Input AND Logic Gate CMOS Surface Mount SC-70 5-Pin NC7SV08P5X
Brand: onsemi
SKU: 242790
Price: 20.22 USD
Availability: InStock



Category Logic Gates Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	900μm
Length	2mm
Model	NC7SV08P5X
Mount Type	Surface
Output type	CMOS
Input Type	CMOS
Maximum Operating Temperature	85°C
Package Type	SC-70
Minimum Operating Temperature	-40°C
Pin Count	5
Number of Elements	1
Maximum Supply Voltage	3.6V
Logic Family	TinyLogic ULP-A
Logic Function	AND
Minimum Supply Voltage	900mV
Maximum High Level Output Current	-24mA
Maximum Propagation Delay Time @ CL	3ns
Maximum Low Level Output Current	24mA
Number of Inputs per Gate	2

Key Features

This logic gate features a 2-input AND function for digital signal processing.
It uses CMOS technology, enabling ultralow power consumption and high noise immunity.
The device is surface mountable with a compact SC-70 5-pin package footprint.
Operating temperature range is from -40°C to 85°C for robust industrial use.
Supports low voltage operation from 0.9 V minimum to 3.6 V maximum supply voltage.
Maximum propagation delay time is 3 nanoseconds, ensuring high-speed switching.
Output current capability includes ±24 mA for flexible load driving.
The package height is only 900 micrometers and length is 2 millimeters, suitable for compact PCB layouts.

Product Description

onsemi NC7SV08P5X is a 2-Input AND Logic Gate utilizing CMOS technology, housed in a compact 5-pin SC-70 surface mount package. It is designed for ultralow power consumption and high-speed digital logic applications.

This component operates under a supply voltage range from 0.9 V to 3.6 V, fitting low voltage circuitry and portable electronic devices. It delivers a maximum propagation delay time of 3 ns ensuring responsive logic switching for advanced signal processing.

The gate provides an output current of up to ±24 mA, supporting a broad range of load requirements. Its operating temperature range of -40°C to 85°C makes it suitable for a variety of industrial environments.

The compact SC-70 package dimensions (900 μm height and 2 mm length) promote dense PCB design and reduced metal trace length, which helps minimize electromagnetic interference (EMI).

onsemi's TinyLogic ULP-A family, to which this device belongs, is optimized for very low power and high speed functionality ideal for consumer electronics, industrial automation systems, and embedded circuit designs.

This logic gate features a 2-input AND function for digital signal processing. It uses CMOS technology, enabling ultralow power consumption and high noise immunity. The device is surface mountable with a compact SC-70 5-pin package footprint.

Operating temperature range is from -40°C to 85°C for robust industrial use. Supports low voltage operation from 0.9 V minimum to 3.6 V maximum supply voltage. Maximum propagation delay time is 3 nanoseconds, ensuring high-speed switching.

Output current capability includes ±24 mA for flexible load driving. The package height is only 900 micrometers and length is 2 millimeters, suitable for compact PCB layouts. Ideal for applications requiring minimal routing complexity and reduced EMI in electronic designs.

Compliant with no specific standards or automotive certification but designed for general industrial and commercial use. Explore more semiconductor components and Logic Gates to optimize your electronic and industrial designs with EnvMart technology products.
