DiodesZetex High Voltage PNP Bipolar Transistor 150 mA 500 V 3-Pin SOT-23 FMMT560TA

DiodesZetex FMMT560TA is a high voltage PNP bipolar junction transistor featuring a maximum DC collector current of 150 mA and collector-emitter voltage of 500 V. Its 3-Pin SOT-23 surface mount package delivers compactness and ease of PCB assembly for electronic and power circuit designs.

This transistor is configured as a single transistor with PNP polarity, supporting a maximum collector base voltage of 500 V and emitter base voltage limit of 5 V. It provides a minimum current gain (hFE) of 80, ensuring efficient amplification and switching in moderate power electronics including signal processing, amplification, and switching circuits.

The FMMT560TA offers a maximum transition frequency (ft) of 60 MHz, making it suitable for mid-range frequency applications. Its power dissipation maximum is 500 mW, requiring appropriate thermal management in high load conditions.

This component operates reliably in a wide temperature range from -55°C to 150°C and conforms to the AEC-Q101 automobile industry standard, supporting reliable performance in harsh automotive and industrial environments.

Measuring approximately 3 mm in length, 2.5 mm in width, and 1.1 mm in height, this device fits densely populated circuit boards without sacrificing performance.

This transistor is ideal for use in industrial, automotive, telecommunications, electronic instrumentation, and consumer electronics applications where high voltage and robustness are critical.

Supports a maximum DC collector current of 150 mA with PNP transistor polarity. Rated for a maximum collector-emitter voltage of 500 V suitable for high voltage applications. Compact SOT-23 package with 3 pins designed for surface mount technology.

Maximum power dissipation of 500 mW ensures reliable thermal performance. Current gain minimum of 80 for efficient switching and amplification. Operating temperature range from -55°C to 150°C ensures performance stability.

Maximum transition frequency of 60 MHz supports moderate frequency applications. Meets AEC-Q101 automotive standard for high reliability in automotive and industrial conditions. Physical dimensions approximately 3 mm x 2.5 mm x 1.1 mm facilitate compact PCB layouts.
