Samtec TSW Series Straight Through Hole Pin Header 10 Contacts 2.54 mm Pitch 1 Row Unshrouded TSW-110-17-T-S
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 4.3A |
| Model | TSW-110-17-T-S |
| Mount Type | Through Hole |
| Special Features | Many options for optimizing cost and performance with platings and ruggedizing features |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 10 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 2.79mm |
| Mating Pin Length | 15.74mm |
| Contact System | .025" (0.635 mm) square post |
Key Features
- Constructed with phosphor bronze contacts plated in tin for reliable conductivity.
- Housing is made from durable polybutylene terephthalate material.
- Supports a current rating of 4.3A and voltage rating of 550V.
- Designed for board-to-board connector systems with through-hole mounting.
- Operates reliably within temperature range of -55°C to 105°C.
- Features 2.79 mm tail pin length and 15.74 mm mating pin length.
- Contact system utilizes a 0.025 inch (0.635 mm) square post for secure connections.
- Ideal for industrial electronics applications requiring rugged pin header solutions.
Product Description
Samtec TSW-110-17-T-S is a high-quality straight through hole pin header designed for electronic components assemblies requiring robust and reliable connections. This unshrouded header features 10 male contacts arranged in a single row, with a precise 2.54 mm pitch and vertical orientation.
The contacts are made from phosphor bronze and plated with tin to ensure superior electrical conductivity and corrosion resistance. The housing is constructed of polybutylene terephthalate, imparting mechanical strength and heat resistance.
This connector supports a nominal current of 4.3 A and voltage up to 550 V, making it suitable for various industrial electronic board-to-board connection systems. It employs through-hole mounting and solder termination for secure attachment to printed circuit boards.
The operating temperature range spans from -55°C to 105°C, enabling reliable performance in harsh environmental conditions. The tail pin length measures 2.79 mm, while the mating pin length extends to 15.74 mm, facilitating firm and consistent connections.
The contact system uses a 0.025 inch (0.635 mm) square post design that combines durability with electrical integrity. This component is widely used in industrial, manufacturing, and electronics assembly applications where dependable pin headers are required.
Constructed with phosphor bronze contacts plated in tin for reliable conductivity. Housing made from durable polybutylene terephthalate material. Supports current rating of 4.3A and voltage rating of 550V. Designed for board-to-board connector systems with through-hole mounting.
Operates within temperature range of -55°C to 105°C. Features 2.79 mm tail pin length and 15.74 mm mating pin length. Contact system utilizes 0.025 inch (0.635 mm) square post. Unshrouded, single row, straight orientation design.
This Samtec TSW series pin header combines multiple options for optimizing cost and performance with specialized plating and ruggedizing features. It is ideal for industrial electronics, manufacturing equipment, laboratory instrumentation, and commercial electronic systems.
Explore more high-quality PCB headers and connectors from leading brands at EnvMart's Electronics Components category.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 4.3 A and a voltage rating of 550 V.
The pitch size of this pin header is 2.54 mm.
The contacts are made from phosphor bronze and are plated in tin, while the housing is constructed from polybutylene terephthalate.
It operates reliably within a temperature range of -55°C to 105°C.
This pin header features 10 male contacts arranged in a single row.
The tail pin length measures 2.79 mm.
It is designed for through-hole mounting with solder termination.
The mating pin length extends to 15.74 mm.
This model supports a board-to-board connector system.
The TSW-110-17-T-S is an unshrouded pin header.
The contact system utilizes a 0.025 inch (0.635 mm) square post design for secure connections.
The country of origin for this pin header is India.
