Molex KK 396 Series Straight Through Hole Pin Header, Unshrouded, 24 Contacts, 3.96 mm Pitch, 1 Row, 7A, 250V 26-48-1245
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Molex |
| Orientation | Straight |
| Current | 7A |
| Mount Type | Through Hole |
| Housing Material | Polyester |
| Contact Material | Brass |
| Series | KK 396 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 3.96mm |
| Standards/Approvals | UL (E29179), CSA (LR19980) |
| Contact Plating | Tin |
| Number of Contacts | 24 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 4.37mm |
Key Features
- 24-contact single row pin header for wire-to-board applications.
- KK 396 Series offers a 3.96 mm pitch for reliable PCB connection.
- Through hole mounting for robust solder attachment.
- Unshrouded, straight orientation and male contacts suitable for a variety of connector systems.
- Polyester housing and tin-plated brass contacts ensure durability and good conductivity.
- Rated for 7A current and up to 250V voltage.
- Supports operating temperature range from -40°C to 105°C.
- Tail pin length is 4.37 mm for secure board insertion.
Product Description
Molex 26-48-1245 KK 396 Series Straight Through Hole Pin Header is designed for wire-to-board applications requiring robust, reliable electrical connection. This component features 24 male contacts arranged in a single row, offering a compact solution with a standard 3.96 mm pitch for compatibility with Molex KK range connectors and various PCB housings.
The header is constructed with a durable polyester housing and tin-plated brass contacts, delivering both high mechanical strength and excellent electrical conductivity. Its straight, unshrouded form facilitates easy integration into PCB designs, while the through-hole mounting and solder termination ensure a secure and stable connection to the board. The tail pins measure 4.37 mm in length, promoting reliable insertion.
Engineered for demanding applications, this pin header supports a 7A current rating and operates up to 250V, suitable for both signal and power transmission in electronic assemblies.
Compatibility with mating Molex KK Series connectors, as well as other industry-standard housings and IDT connectors, allows for straightforward system integration. The unshrouded, male contact configuration is ideal where quick, versatile connectivity is needed.
UL and CSA approved, this pin header is widely used in electronics manufacturing, control panels, power distribution assemblies, and instrumentation. Its high durability and precise design have made it a reliable choice for builders, engineers, and designers seeking robust PCB connector solutions.
Discover more Molex KK 396 Series and similar PCB headers and connectors in the Electronics & Electricals category for advanced industrial and electronic projects.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 7A, making it suitable for both signal and power transmission in electronic assemblies.
It is rated for a maximum voltage of 250V, ensuring it can handle various electrical applications safely.
The contacts are arranged with a pitch of 3.96 mm, which is standard for compatibility with various PCB housings and connectors.
This pin header features 24 male contacts arranged in a single row, allowing for multiple connections in a compact design.
The housing is made of polyester, while the contacts are constructed from brass with tin plating for good conductivity.
The tail pin length measures 4.37 mm, which aids in secure board insertion during installation.
It supports an operating temperature range from -40°C to 105°C, making it suitable for various environmental conditions.
Yes, it is compatible with Molex KK Series connectors as well as other industry-standard housings and IDT connectors for easy integration.
This model uses through hole mounting, which provides a robust solder attachment to the PCB.
This pin header is UL and CSA approved, ensuring it meets safety and performance standards for electronic components.
The contacts are in a straight orientation, which facilitates easy integration into PCB designs.
It utilizes solder termination, ensuring a secure connection to the PCB during assembly.
