onsemi 200 V 16 A General Purpose Rectifier Diode, 3-Pin TO-220AB Package BYV32-200G
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 9.28mm |
| Length | 10.28mm |
| Model | BYV32-200G |
| Width | 4.82mm |
| Mount Type | Through Hole |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-220AB |
| Minimum Operating Temperature | -65°C |
| Pin Count | 3 |
| Maximum Continuous Forward Current If | 16A |
| Peak Reverse Repetitive Voltage Vrrm | 200V |
| Diode Configuration | Common Cathode |
| Rectifier Type | General Purpose |
| Peak Reverse Current Ir | 50μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 100A |
| Maximum Forward Voltage Vf | 1.15V |
| Peak Reverse Recovery Time trr | 35ns |
Key Features
- Designed for through-hole mounting with TO-220AB package type.
- Maximum continuous forward current of 16 amperes for robust conduction.
- Peak reverse repetitive voltage of 200 volts supports various power applications.
- Common cathode diode configuration ensures compatibility with standard circuits.
- Low maximum forward voltage of 1.15 volts enhances efficiency.
- Operates reliably across a temperature range from -65°C to 175°C.
- Peak non-repetitive forward surge current of 100 amperes for transient conditions.
- Fast peak reverse recovery time of 35 nanoseconds improves switching performance.
Product Description
onsemi BYV32-200G is a general purpose rectifier diode designed for industrial and electronic semiconductor applications. It features a peak reverse voltage of 200 V and can continuously handle forward currents up to 16 A. The diode is housed in a through-hole TO-220AB package with 3 pins, optimized for secure mounting and efficient heat dissipation.
This component is ideal for use in power rectification circuits, power supplies, and other industrial equipment requiring reliable diode performance. The common cathode configuration enables compatibility with various circuit designs.
It supports a wide operating temperature range from -65°C to 175°C, ensuring durability in demanding environments. The diode boasts a fast peak reverse recovery time of 35 ns, making it suitable for applications where quick switching is essential. Peak surge currents up to 100 A withstand transient stress during operation.
Physical dimensions are concise with a length of 10.28 mm, width of 4.82 mm, and height of 9.28 mm. The maximum forward voltage drop is limited to 1.15 V for energy-efficient switching.
This product is not automotive standard qualified and does not have specific industry certifications. Used primarily in electronics manufacturing, power supplies, and semiconductor projects.
Designed for through-hole mounting with TO-220AB package type. Maximum continuous forward current of 16 amperes for robust conduction. Peak reverse repetitive voltage of 200 volts supports various power applications. Common cathode diode configuration ensures compatibility with standard circuits.
Low maximum forward voltage of 1.15 volts enhances efficiency. Operates reliably across a temperature range from -65°C to 175°C. Peak non-repetitive forward surge current of 100 amperes for transient conditions. Fast peak reverse recovery time of 35 nanoseconds improves switching performance.
Compact physical dimensions: length 10.28 mm, width 4.82 mm, height 9.28 mm. Not automotive standard qualified and no special certifications applied. Explore onsemi semiconductor diodes and other components on EnvMart for reliable industrial electronic solutions.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of this model is 16 amperes.
It has a peak reverse repetitive voltage rating of 200 volts.
This diode is housed in a TO-220AB package type, designed for through-hole mounting.
The maximum forward voltage drop for this model is 1.15 volts.
This unit can withstand a peak non-repetitive forward surge current of 100 amperes.
It operates reliably across a temperature range from -65°C to 175°C.
The peak reverse recovery time is 35 nanoseconds, enhancing its switching performance.
The dimensions of this model are 10.28 mm in length, 4.82 mm in width, and 9.28 mm in height.
It features a common cathode diode configuration, ensuring compatibility with standard circuits.
No, this product is not automotive standard qualified and does not have specific industry certifications.
It is suitable for power rectification circuits, power supplies, and other industrial equipment requiring reliable diode performance.
This model has a pin count of 3.
