onsemi 40 V 3 A Switching Schottky Diode 3-Pin DPAK MBRD340T4G
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 2.38mm |
| Length | 6.73mm |
| Model | MBRD340T4G |
| Width | 6.22mm |
| Mount Type | Surface |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-252 |
| Minimum Operating Temperature | -65°C |
| Standards/Approvals | RoHS |
| Pin Count | 3 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 3A |
| Peak Reverse Repetitive Voltage Vrrm | 40V |
| Diode Configuration | Single |
| Rectifier Type | Switching |
| Peak Reverse Current Ir | 200μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 75A |
| Maximum Forward Voltage Vf | 0.7V |
Key Features
- Surface mount TO-252 package ensures ease of PCB assembly.
- Maximum continuous forward current rating of 3 A supports robust applications.
- Peak reverse repetitive voltage is 40 V, suitable for low voltage circuits.
- Low forward voltage of 0.7 V reduces power loss in high-frequency switching.
- Operating temperature range from -65°C up to 175°C supports rugged environments.
- Compact 3-pin DPAK design minimizes board space.
- RoHS compliant with AEC-Q101 automotive standard qualification.
- Epoxy moulded lightweight package weighing approximately 11.7 mg.
Product Description
onsemi MBRD340T4G is a high-performance switching Schottky diode designed for surface mount applications in electronics and electrical systems. It features a compact 3-pin DPAK (TO-252) epoxy moulded package, making it suitable for densely packed circuit boards where space and weight savings are critical.
This diode supports a maximum continuous forward current of 3 A and a peak reverse repetitive voltage of 40 V, making it ideal for low voltage, high frequency rectification tasks. The low forward voltage drop of 0.7 V reduces overall power losses, enhancing efficiency in power management circuits.
The device is designed to operate reliably over a wide temperature range from -65°C to 175°C, making it robust for various industrial and automotive environments. The package conforms to RoHS standards and meets the AEC-Q101 automotive qualification, ensuring quality and compliance for automotive and industrial use cases.
The MBRD340T4G diode integrates stress protection features and is built with Pb-free materials, supporting environmentally friendly manufacturing processes. Its lightweight design aids in automated assembly lines, improving production efficiency.
Common applications include use as a freewheeling diode, polarity protection diode, and switching diode in power supplies, consumer electronics, automotive electronics, and industrial manufacturing circuits requiring compact, energy-efficient Schottky barrier devices.
Surface mount TO-252 package for compact PCB design and automated assembly. Maximum continuous forward current of 3 A supports numerous power applications. Peak reverse repetitive voltage of 40 V for low voltage switching environments.
Low forward voltage drop of 0.7 V improves energy efficiency. Wide operating temperature range from -65°C to 175°C for harsh conditions. Meets RoHS compliance and AEC-Q101 automotive standards for quality assurance. Lightweight epoxy moulded case weighing approximately 11.7 mg.
Designed for low voltage, high-frequency rectification and protection functions. Pb-free construction suited for environmentally conscious applications. Package supports stress protection and automated board assembly. Explore more semiconductor products like Schottky diodes and rectifiers to enhance your electronic assemblies at EnvMart.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current rating of this model is 3 A.
It has a peak reverse repetitive voltage of 40 V, making it suitable for low voltage circuits.
The forward voltage drop is 0.7 V, which helps reduce power loss in high-frequency switching applications.
This diode operates reliably over a temperature range from -65°C to 175°C.
It comes in a compact TO-252 package, also known as a 3-pin DPAK design, which is suitable for surface mount applications.
This model is RoHS compliant and meets the AEC-Q101 automotive standard for quality assurance.
The diode weighs approximately 11.7 mg, making it lightweight for automated assembly.
Common applications include use as a freewheeling diode, polarity protection diode, and switching diode in various electronic circuits.
The peak non-repetitive forward surge current is rated at 75 A.
This model features a pin count of 3, suitable for its DPAK configuration.
It is classified as a switching rectifier, designed for high-frequency rectification tasks.
The peak reverse current is specified at 200 μA.
