onsemi Small Signal NPN Transistor 100 mA 45 V 3-Pin SOT-23 BCW72LT1G

onsemi BCW72LT1G is a small signal NPN bipolar transistor designed for efficient amplification and switching in electronic circuits. It supports a maximum collector current of 100 mA with a collector-emitter voltage of up to 45 V, making it ideal for low power signal applications.

Packaged in a small 3-pin SOT-23 surface mount form factor, the BCW72LT1G enables high-density PCB layouts and automated manufacturing processes. The transistor exhibits a minimum DC current gain (hFE) of 200, ensuring effective amplification and reliable performance in various electronic devices.

Operating temperature range from -55°C to 150°C ensures durability and stability in demanding environments including automotive electronics, industrial control systems, and consumer electronic devices. This transistor is also qualified to the AEC-Q101 automotive standard, affirming its robustness for automotive applications.

With a maximum power dissipation of 300 mW and a transition frequency of 300 MHz, the BCW72LT1G supports high-speed switching suitable for signal processing and amplification tasks.

Maximum collector current of 100 mA. Maximum collector-emitter voltage of 45 V. Compact SOT-23 surface mount package. Minimum current gain hFE of 200. Operating temperature range -55°C to 150°C. AEC-Q101 automotive qualified.

Maximum power dissipation of 300 mW. High transition frequency of 300 MHz. 3-pin configuration for easy PCB integration.

This transistor is well suited for applications in electronic circuits that require compact design, reliable switching and amplification, such as automotive electronics, instrumentation, telecommunications, and industrial electronics.
