DiodesZetex Darlington Transistor PNP, -500 mA Collector Current, 30 V Collector Emitter Voltage, 3-Pin SOT-23 MMBTA63-7-F

DiodesZetex MMBTA63-7-F is a PNP Darlington transistor designed for efficient switching and amplification in electronic circuits. It features a maximum continuous collector current of -500 mA, with a maximum collector emitter voltage of 30 V, making it suitable for medium-power applications. The transistor is housed in a compact 3-pin SOT-23 surface mount package, enabling easy integration into printed circuit boards where space is limited.

The device delivers a minimum DC current gain hFE of 10000, providing excellent amplification capabilities. With a maximum power dissipation rating of 300 mW, this transistor supports reliable operation under moderate thermal loads. Operating temperature spans from -55°C to 150°C, suitable for harsh industrial and automotive environments. Notably, the transistor complies with the automotive AEC-Q101 standard, affirming its suitability for automotive electronic systems.

The transistor’s maximum emitter base and collector base voltages of -10 V and -30 V respectively ensure operational stability and protection within circuit designs. Additionally, the extremely low maximum collector cut-off current of -100 nA reduces current leakage, enhancing circuit efficiency and performance.

This device finds applications in industrial control systems, automotive electronics, telecommunications, and other electronic assembly processes requiring compact, high-gain PNP Darlington transistors. The small footprint and surface mounting facilitate automated assembly and high-volume production.

PNP transistor polarity for switching and amplification. High current gain with minimum DC current gain of 10000. Power dissipation rated at 300 mW for reliable operation. Wide operating temperature range from -55°C to 150°C.

Compact SOT-23 3-pin surface mount package. Automotive standard AEC-Q101 certified for vehicle applications. Stable operation with maximum emitter base voltage of -10 V. Low collector cut-off current minimises leakage.

Package contents include the single Darlington Transistor component in the specified configuration. This product supports various electronic and industrial manufacturing requirements. Explore more components and related semiconductor devices in the DiodesZetex range on EnvMart for your project needs.
