DiodesZetex Bridge Rectifier, 100 V Peak Reverse Voltage, 8 A Peak Non-Repetitive Forward Surge Current SBR05M100BLP-7
Specifications
| Country of Origin | India |
|---|---|
| Brand | DiodesZetex |
| Height | 3.1mm |
| Length | 3.1mm |
| Model | SBR05M100BLP-7 |
| Width | 3.1mm |
| Mount Type | Surface |
| Series | SBR |
| Configuration | Single |
| Maximum Operating Temperature | 150°C |
| Package Type | DFN |
| Minimum Operating Temperature | -55°C |
| Number of Phases | 1 |
| Pin Count | 4 |
| Peak Reverse Repetitive Voltage Vrrm | 100V |
| Peak Reverse Current Ir | 250μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 8A |
| Forward Current If | 500mA |
| Peak Forward Voltage Vf | 730mV |
Key Features
- This bridge rectifier features a peak reverse voltage of 100 V.
- It supports a forward current of 500 mA and peak surge current of 8 A.
- The device has a compact size of 3.1 mm by 3.1 mm by 3.1 mm.
- Operates reliably between -55°C and 150°C maximum operating temperatures.
- It offers soft and fast switching capability for efficient power conversion.
- The package type is DFN with 4 pins in single phase configuration.
- Peak forward voltage is 730 mV ensuring efficient conduction.
- Peak reverse current is minimal at 250 μA to reduce leakage losses.
Product Description
DiodesZetex SBR05M100BLP-7 Bridge Rectifier is a high-performance semiconductor device specifically engineered with a surface mount DFN package. It operates with a peak reverse repetitive voltage rating of 100 V and a forward continuous current of 500 mA, making it suitable for a wide range of electronic applications requiring AC to DC conversion.
This device features ultra low leakage current and exceptional thermal stability up to 150°C, ensuring reliable performance in demanding industrial and commercial environments. Its compact form factor with dimensions of 3.1 mm height, width, and length allows efficient space utilization on printed circuit boards.
The bridge rectifier provides a single-phase configuration with 4 pins, offering soft and fast switching capabilities that optimize efficiency in power supplies and converters. Designed for surface mounting, it eases automated assembly processes and improves production throughput.
100 V peak reverse voltage for robust electrical endurance. 500 mA forward current rating suitable for low to medium power circuits. 8 A peak non-repetitive forward surge current for transient protection. Compact 3.1 mm × 3.1 mm × 3.1 mm DFN package.
Operating temperature range from -55°C to 150°C supports harsh environments. Low peak forward voltage and minimal reverse current reduce power losses. Reliable surface mount design supports modern electronic manufacturing.
This Bridge Rectifier is widely applicable in industrial machines, power supplies, consumer electronics, HVAC systems, and automotive electrical circuits. Its high temperature tolerance and stable performance improve the reliability and longevity of systems incorporating it. EnvMart offers this component for applications demanding efficient and compact AC to DC rectification solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The SBR05M100BLP-7 has a peak reverse repetitive voltage rating of 100 V.
This model supports a forward current of 500 mA.
The package dimensions are 3.1 mm in height, width, and length.
It operates reliably at a maximum temperature of 150°C.
The peak non-repetitive forward surge current is rated at 8 A.
The peak forward voltage is 730 mV, ensuring efficient conduction.
The minimum operating temperature is -55°C.
This bridge rectifier features a 4-pin configuration.
It supports surface mounting, facilitating automated assembly processes.
The peak reverse current is minimal at 250 μA, which helps reduce leakage losses.
It is applicable in industrial machines, power supplies, consumer electronics, HVAC systems, and automotive electrical circuits.
The configuration of this model is single-phase.
