onsemi Schottky Diode 80 V 1 A Surface Mount DO-214AC Package 2-Pin SS18
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 2.2mm |
| Length | 4.75mm |
| Model | SS18 |
| Width | 2.95mm |
| Mount Type | Surface |
| Series | SS18 |
| Maximum Operating Temperature | 125°C |
| Package Type | DO-214AC |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 1A |
| Peak Reverse Repetitive Voltage Vrrm | 80V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 10mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 40A |
| Maximum Forward Voltage Vf | 850mV |
Key Features
- Designed for efficient low forward voltage drop with a maximum of 850 mV.
- Supports a peak non-repetitive forward surge current of up to 40 A.
- Operates reliably over a temperature range from -65°C to 125°C.
- Compact dimensions of 4.75 mm length, 2.95 mm width, and 2.2 mm height.
- Ideal for use in electronic circuits requiring Schottky barrier rectifier diodes for fast switching and low power loss.
- Single diode configuration with a pin count of 2 for simple implementation.
- Non-automotive standard component suitable for general electronics and power applications.
- Surface mount mount type enables efficient PCB assembly.
Product Description
onsemi SS18 is a surface mount Schottky diode designed to deliver reliable performance with an 80 V peak reverse repetitive voltage and 1 A continuous forward current. Presented in a durable DO-214AC package, this 2-pin diode offers a low forward voltage drop up to 850 mV, reducing power loss and heat in electronic circuits. Its compact size, measuring 4.75 mm in length, 2.95 mm in width, and 2.2 mm in height, allows it to be used effectively in space-constrained applications.
This Schottky diode operates over a wide temperature range from -65°C up to 125°C, ensuring suitability for demanding industrial, electronic component manufacturing, power supply design, and semiconductor applications. It supports a peak surge current up to 40 A, allowing it to handle sudden load changes and transient conditions efficiently.
Its single diode configuration and two-pin design simplify integration onto PCBs with surface mount technology, enhancing production efficiency and reliability in assembly processes. The component does not comply with automotive standards but provides high-quality performance for general electronic component needs.
The SS18 diode is ideal for use in industrial electronics, power rectification, switching applications, and electronic circuit protection requiring robust low loss rectifiers. Its advanced semiconductor design from onsemi combines quality, durability, and efficient electrical characteristics to meet contemporary design requirements.
Low forward voltage drop for power efficiency. Wide operating temperature range ensures reliability. Compact DO-214AC package suitable for surface mounting. High surge current capability to withstand transient conditions.
Single diode configuration for simplified design. Optimized for use in power rectifiers and switching circuits. Non-automotive certified, optimized for general electronics. Explore a wide range of semiconductors and Schottky diodes at EnvMart for your industrial, electronic, and power application needs.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum forward voltage of this Schottky diode is 850 mV.
This model has a peak reverse repetitive voltage rating of 80 V.
The continuous forward current capacity of this diode is 1 A.
It can handle a peak non-repetitive forward surge current of up to 40 A.
This diode operates reliably over a temperature range from -65°C to 125°C.
The dimensions of this diode are 4.75 mm in length, 2.95 mm in width, and 2.2 mm in height.
The package type for this diode is DO-214AC.
This model features a single diode configuration with a pin count of 2.
The mount type for this diode is surface mount.
This diode does not comply with automotive standards and is optimized for general electronics.
This model is a Schottky rectifier.
The peak reverse current for this diode is specified at 10 mA.
