onsemi Bridge Rectifier 600 V 300 A 4-Pin Single GBPC2506W
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 11.23mm |
| Length | 29mm |
| Model | GBPC2506W |
| Width | 29mm |
| Mount Type | Through Hole |
| Series | GBPC25 |
| Configuration | Single |
| Maximum Operating Temperature | 150°C |
| Package Type | GBPC |
| Minimum Operating Temperature | -55°C |
| Number of Phases | 1 |
| Pin Count | 4 |
| Peak Reverse Repetitive Voltage Vrrm | 600V |
| Peak Reverse Current Ir | 500μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 300A |
| Forward Current If | 25A |
| Peak Forward Voltage Vf | 1.1V |
Key Features
- Peak reverse repetitive voltage of 600 volts for high voltage endurance.
- Supports continuous forward current of 25 amps for stable operation.
- Operates reliably between -55°C and 150°C maximum temperature.
- Glass passivated die construction enhances durability and heat dissipation.
- Integrally molded heat sink minimizes thermal resistance for efficient cooling.
- Isolated voltage from case to lead exceeds 2500 volts for electrical safety.
- Compact dimensions with height 11.23 mm and length 29 mm.
- Fast-on push terminals enable easy mounting and connection.
Product Description
onsemi GBPC2506W Bridge Rectifier is a high-performance 4-pin single-phase device engineered for reliable power rectification in various industrial and electronic applications. Rated for peak reverse repetitive voltage of 600 V and a maximum forward current of 25 A, it is optimized to operate over a wide temperature range from -55°C to 150°C, thereby ensuring durability under demanding thermal conditions.
The bridge rectifier incorporates a glass passivated die construction paired with an integrally molded heat sink, enabling low thermal resistance and effective heat dissipation. This design enhances device longevity and improves operational stability. The component’s isolated voltage rating from case to lead exceeds 2500 V, providing significant insulation and safety.
Dimensionally compact at 29 mm length, 29 mm width, and 11.23 mm height, the GBPC2506W is suitable for through-hole mounting with fast-on terminals allowing quick installation in power supply circuits, motor controllers, and industrial electronics.
Peak reverse repetitive voltage rated at 600 V. Forward current capacity of 25 A. Operating temperature range from -55°C to 150°C. Peak non-repetitive forward surge current up to 300 A. Low forward voltage drop at 1.1 V enhancing efficiency.
Compact and robust package type GBPC. Push-on terminals facilitate efficient assembly. Certified with UL approval #E258596 for quality assurance.
This bridge rectifier is ideal for use in industrial machines, power supplies, electronic control systems, and other environments requiring robust and efficient rectification solutions. Its automotive standard is not specified, focusing on general electrical and industrial applications.
Explore more high-quality semiconductor components and Bridge Rectifiers available at EnvMart, tailored for professional and commercial electronic manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The GBPC2506W has a peak reverse repetitive voltage rating of 600 V, making it suitable for high voltage applications.
This model supports a maximum forward current of 25 A, ensuring stable operation in various applications.
It operates reliably between -55°C and 150°C, allowing for use in extreme thermal conditions.
The peak non-repetitive forward surge current for this rectifier is rated at 300 A, providing robust performance during surges.
This bridge rectifier has a compact size with a length and width of 29 mm, and a height of 11.23 mm.
It is designed for through-hole mounting, which facilitates easy installation in various electronic circuits.
The GBPC2506W features fast-on push terminals, allowing for quick and efficient connections during installation.
The forward voltage drop for this bridge rectifier is 1.1 V, which enhances its efficiency during operation.
It has an isolated voltage rating from case to lead that exceeds 2500 V, providing significant electrical safety.
This model features a glass passivated die construction, which enhances durability and heat dissipation.
It is suitable for power supplies, motor controllers, and various industrial electronics requiring efficient rectification.
The GBPC2506W is manufactured in India, ensuring compliance with local manufacturing standards.
