onsemi 40 V 500 mA Schottky Diode 2-Pin Surface Mount SOD-123 MBR0540T3G

onsemi MBR0540T3G is a high-performance Schottky barrier diode engineered with advanced barrier metal technology achieving an optimal forward voltage drop and minimizing reverse current leakage.

This 2-pin surface mount diode in the SOD-123 package is well suited for low voltage, high-frequency rectification tasks including freewheeling and polarity protection in diverse electronic circuits.

It supports a maximum continuous forward current of 500 mA and a peak reverse repetitive voltage of 40 V, ensuring robust operation in various electronics manufacturing and industrial applications.

Key electrical capabilities include a maximum forward voltage of 610 mV and the ability to withstand surge currents of up to 5.5 A non-repetitively. The device is qualified to AEC-Q101 automotive standards, making it suitable for automotive and other demanding environments.

The compact dimensions (2.84 mm length by 1.8 mm width by 1.25 mm height) and the lightweight epoxy moulded case enable highly reliable automated PCB assembly and efficient space utilization in electronic designs.

Low forward voltage drop ensures efficient power handling. High surge current rating improves device robustness. Wide operating temperature range enables versatility. AEC-Q101 automotive qualification guarantees quality and reliability.

Compact SOD-123 package supports automated assembly processes. Single diode configuration for straightforward implementation. Epoxy moulded case provides mechanical and environmental protection. Low weight contributes to reduced overall device mass in applications.

This onsemi Schottky diode is ideal for use in industrial, automotive, telecommunications, and consumer electronic applications where efficient rectification and protection are required.
