onsemi Schottky Diode 40 V 120 mA Surface Mount 3-Pin SOT-23 BAS40-06LT1G

Free Delivery in India | Lowest Global Shipping Charges

onsemi Schottky Diode 40 V 120 mA Surface Mount 3-Pin SOT-23 BAS40-06LT1G

Name: onsemi Schottky Diode 40 V 120 mA Surface Mount 3-Pin SOT-23 BAS40-06LT1G
Brand: onsemi
SKU: 131829
Price: 0.04 USD
Availability: InStock



Category Schottky Diodes & Rectifiers Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	1.01mm
Length	3.04mm
Model	BAS40-06LT1G
Width	1.4mm
Mount Type	Surface
Maximum Operating Temperature	150°C
Package Type	SOT-23
Minimum Operating Temperature	-55°C
Pin Count	3
Automotive Standard	AEC-Q101
Maximum Continuous Forward Current If	120mA
Peak Reverse Repetitive Voltage Vrrm	40V
Diode Configuration	Common Anode
Rectifier Type	Schottky
Peak Reverse Current Ir	1μA
Peak Non-Repetitive Forward Surge Current Ifsm	600mA
Maximum Forward Voltage Vf	380mV

Key Features

Designed using Schottky barrier technology for low forward voltage and reverse current.
Compact 3-pin SOT-23 surface mount package providing minimal footprint.
Maximum continuous forward current of 120 mA ensures reliable low-current rectification.
Peak reverse repetitive voltage of 40 V suitable for low voltage circuits.
Operating temperature range from -55°C to 150°C supports harsh environments.
Peak non-repetitive forward surge current rated up to 600 mA.
Lightweight epoxy molded case weighing approximately 11.7 mg.
AEC-Q101 automotive qualified for enhanced reliability in vehicle systems.

Product Description

onsemi BAS40-06LT1G is a Schottky Barrier Diode designed for low voltage and high-frequency rectification in various surface mount electronic applications. Featuring a 3-pin SOT-23 package, this diode minimizes size and weight while delivering efficient forward voltage drop and reduced reverse current characteristics.

This diode offers a maximum continuous forward current of 120 mA and a peak reverse repetitive voltage of 40 V, making it ideal for use as freewheeling and polarity protection in automotive and industrial circuits. It supports an operating temperature range from -55°C to 150°C, suitable for rugged environments.

The device is epoxy molded for stress protection, ensuring durability during automated board assembly processes. Its lightweight design at 11.7 mg contributes to compact electronic assemblies. Additionally, the BAS40-06LT1G meets the AEC-Q101 automotive standard, ensuring high reliability for automotive electronics.

Designed using Schottky barrier principle for optimal performance. Compact 3-pin SOT-23 surface mount package reduces board space. Forward current rating of 120 mA supports low power applications. Peak reverse voltage of 40 V suitable for low voltage protection.

Wide temperature range from -55°C to 150°C for diverse applications. Epoxy molded case provides stress protection and robustness. Lightweight at 11.7 mg for ease of integration. AEC-Q101 qualification suitable for automotive use cases.

This Schottky diode is widely used in industrial electronics, power supply circuits, automotive applications, and other environments requiring efficient low voltage rectification and protection. Its compact form factor and automotive-grade reliability make it suitable for manufacturing, HVAC, and commercial electronics sectors.

Explore more semiconductor solutions and Schottky diodes at EnvMart to find components tailored to your project requirements.

Explore more products in our Schottky Diodes & Rectifiers category.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The maximum continuous forward current of the BAS40-06LT1G is 120 mA, making it suitable for low power applications.

This diode has a peak reverse repetitive voltage rating of 40 V, which is suitable for low voltage circuits.

The BAS40-06LT1G operates within a temperature range of -55°C to 150°C, allowing it to function in harsh environments.

It comes in a compact 3-pin SOT-23 surface mount package, which minimizes board space.

The BAS40-06LT1G weighs approximately 11.7 mg, contributing to lightweight electronic assemblies.

This model has a peak non-repetitive forward surge current rated up to 600 mA.

The BAS40-06LT1G meets the AEC-Q101 automotive standard, ensuring enhanced reliability in vehicle systems.

The maximum forward voltage drop for the BAS40-06LT1G is 380 mV, which supports efficient low voltage rectification.

This model uses a common anode diode configuration, suitable for various applications.

The peak reverse current for the BAS40-06LT1G is rated at 1 μA, indicating low reverse leakage.

The dimensions of the BAS40-06LT1G are 3.04 mm in length, 1.4 mm in width, and 1.01 mm in height.

It is widely used in industrial electronics, power supply circuits, automotive applications, and environments requiring efficient low voltage rectification and protection.
