onsemi Transistor 500 mA NPN 300 V DC 3-Pin DPAK MJD340G

Free Delivery in India | Lowest Global Shipping Charges

onsemi Transistor 500 mA NPN 300 V DC 3-Pin DPAK MJD340G

Name: onsemi Transistor 500 mA NPN 300 V DC 3-Pin DPAK MJD340G
Brand: onsemi
SKU: 131738
Price: 0.48 USD
Availability: InStock



Category Bipolar Transistors Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	0.09mm
Length	6.73mm
Model	MJD340G
Width	2.38mm
Mount Type	Surface
Series	MJD340
Maximum Operating Temperature	150°C
Package Type	TO-252
Minimum Operating Temperature	-65°C
Pin Count	3
Maximum Collector Emitter Voltage Vceo	300V dc
Minimum DC Current Gain hFE	30
Transistor Polarity	NPN
Maximum Emitter Base Voltage VEBO	3V
Maximum Collector Base Voltage VCBO	300V dc
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	15W
Maximum DC Collector Current Idc	500mA
Transistor Configuration	Single
Maximum Transition Frequency ft	10MHz
onsemi MJD340TF NPN Transistor, 500 mA, 300 V, 3-Pin DPAKBrand	ON Semiconductor

Key Features

This transistor offers a maximum DC collector current of 500 mA.
It supports a maximum collector emitter voltage of 300 V DC.
The package type is TO-252 designed for surface mount technology.
The transistor has a minimum DC current gain (hFE) of 30 for reliable amplification.
Maximum power dissipation is rated at 15 W for thermal management efficiency.
This device operates within a temperature range from -65°C to 150°C.
It features a maximum transition frequency of 10 MHz appropriate for switching circuits.
Pin count is 3, facilitating easy integration on PCBs.

Product Description

The onsemi MJD340G is a high-performance NPN bipolar transistor designed for electronic component applications requiring efficient switching and amplification. With a maximum DC collector current of 500 mA and collector emitter voltage up to 300 V DC, this transistor is suitable for medium power circuits and industrial usage.

Packaged in a TO-252 (DPAK) surface mount case with 3 pins, it ensures compact mounting on printed circuit boards. The transistor configuration is single, making it versatile for various signal and power applications.

The device offers a minimum DC gain (hFE) of 30 and a maximum power dissipation of 15 W, balancing electrical performance with thermal safety in demanding environments. Operating temperature spans from -65°C to 150°C, making it suitable for industrial and automotive applications.

This transistor complies with automotive standard AEC-Q101, demonstrating its suitability for rigorous automotive electronic environments. Its maximum transition frequency of 10 MHz supports applications requiring rapid switching response.

Key technical features include a maximum collector base voltage of 300 V DC, emitter base voltage of 3 V, and physical dimensions with length 6.73 mm, width 2.38 mm, and height 0.09 mm. The product is a new unit manufactured in India, branded by onsemi with MPN MJD340G.

Maximum DC collector current: 500 mA. Maximum collector emitter voltage: 300 V DC. Package type: TO-252 surface mount. Minimum DC current gain (hFE): 30. Maximum power dissipation: 15 W. Operating temperature range: -65°C to 150°C.

Maximum transition frequency: 10 MHz. Pin count: 3. Automotive standard AEC-Q101 compliant.

This transistor is suited for industrial, automotive, and manufacturing electronic applications requiring durable and efficient semiconductor switching devices. For more quality bipolar transistors and semiconductor components, browse the Electronics & Electricals > Semiconductor > Bipolar Transistors category at EnvMart.
